Parts List for SHLM-10A
SER.NO. PART.NO. PART NAME SER.NO. PART.NO.
PART NAME
1
10-1
Flat Beater
70
10-70
Inner gear
2
10-2
Hook
71
10-71
hexagon socket cap screws
3
10-3
Wire whip
72
10-72
Circlips for shaft
4
10-4
Gear box
73
10-73
Planet gear
5
10-5
Circlips for shaft
74
10-74
Operating shelf
6
10-6
Worm pole
75
30-76
Bearing
7
10-7
Oil seal
76
10-76
Running shaft support
8
10-8
Key
77
30-76
Bearing
9
10-9
Motor(110v 60Hz with the tools)
78
10-78
Oil seal
10
10-10
fan
79
10-79
Key ：5X20
11
10-11
Back cover
80
10-80
running spindle
12
10-12
Nut:M5X60
81
10-81
Retainer-spring
13
10-13
Spring washer
82
10-82
Bowl
14
10-14
Connector
83
10-83
cross recess pan head screw
15
10-15
Nut:M4X8
84
10-84
Moving frame clamp
16
10-16
Red button
85
10-85
front shield
17
10-17
Green button
86
10-86
back shield
18
10-18
Nut:M4X8
87
10-87
hexagonal head bolt
19
10-19
Brand
88
10-88
Bump pin block
20
10-20
Nut:M4X20
89
10-89
cross recessed countersunk head screw
21
10-21
The micro switch installation
90
10-90
Allen flat end set screws
22
10-22
Distance switch
91
10-91
steel ball
23
10-23
Nob
92
10-92
Taper pin column
24
10-24
Speed handle
93
10-93
Support
25
10-25
Nut:M4X8
94
10-94
Spring washer
26
10-26
fix seat
95
10-95
Type 1 hexagonal nut
27
10-27
Spring
96
10-96
cross recessed countersunk head screw
28
10-28
steel ball
97
10-97
Support lifting climbing
29
10-29
Retainer-spring
98
10-98
hexagon lock nut
30
10-30
nob
99
10-99
flat washer
31
10-31
deep groove ball bearing
100
10-100
compression spring
32
10-32
Plug
101
10-101
flat washer
33
10-33
Spring
102
10-102
elastic cylindrical pin
34
10-34
Roller：6X10
103
10-103
Connecting rod
35
10-35
Gear
104
10-104
cotter
36
10-36
Super machine parts
105
10-105
Retainer-spring
37
10-37
ring gasket
106
10-106
Crank lever
38
10-38
Combination of gear
107
10-107
Handle
39
10-39
Gear shaft sleeve
108
10-108
Stud
40
10-40
Claw-type clutch
109
10-109
hexagonal head bolt
41
10-41
Key ：5X25
110
10-110
foundation
42
10-42
Key ：5X30
111
10-111
hexagonal head bolt
43
10-43
Key ：5X30
112
10-112
Power cord
44
10-44
Main shaft
113
10-113
Power supply is waterproof connectors
45
10-45
Gear shaft sleeve
114
10-114
cross recess pan head screw
46
10-46
Gear
115
10-115
Contact switch
47
10-47
Spring washer
116
10-116
Channeling coil
48
30-36
Bearing
117
10-117
electricity box
49
10-49
Oil seal
118
10-118
Electrical box cover plate
50
10-50
Bearing
119
10-119
M4X8 Stainless steel cross trough pan head
screws
51
10-51
Gear shaft
120
10-120
M4X8 cross recessed countersunk head screw
52
10-52
Key ：5X10
121
10-121
Capacitor
53
10-53
Key ：5X10
122
10-122
Capacitor
54
10-54
Combination of gear
123
10-123
cross recess pan head screw
55
10-55
Circlips for shaft：55
124
10-124
Travel switch fixed plate
56
10-56
Gear
125
10-125
cross recess pan head screw
57
10-57
Circlips for shaft
126
10-126
Type 1 hexagonal nut
58
10-58
Bearing
127
10-127
Travel switch bracket
59
10-59
Bearing
128
10-128
Distance switch
60
10-60
Key ：5X14
129
10-129
cross recess pan head screw
61
10-61
Shaft worm gear
130
10-130
Type 1 hexagonal nut
62
10-62
Worm gear
131
10-131
Shield compression spring
63
10-63
Circlips for shaft
132
10-132
Switch shaft pin
64
10-64
Bearing
133
10-133
split washer
65
30-7
Control nut
134
10-134
Switch shaft pin compression spring
66
10-66
Spring 135
10-135
Overload switch
67
10-67
Fork pin
136
10-136
Timer(with four screws)
68
10-68
declutch shift shaft
137
10-137
Timer knob
69
10-69
Shifting yoke
