Installation Instructions
11. Connecting the overflow line: The brine overflow fitting is located on the
outside of the salt container approximately 12” down from the top. Connect 1/2” drain
tubing to the overflow fitting and run it to the nearest floor drain. This line is a gravity
flow line and cannot be run overhead or cannot connect to a drain that is higher than
the overflow fitting.
12. Connecting the brine line (Figure 6): A 3/8” brine line approximately 4’ long is
attached to the salt container and is supplied with the tube insert in the end of the
brine line. Insert the brine line into the brine fitting (#3) firmly making sure that it is
fully seated. You will notice some resistance when the brine line encounters the o-
ring inside of the brine elbow. Caution: If the brine line is not inserted completely, the
tubing will leak from this point. Verify that there are no leaks during the start-up
procedure.
The water softener is equipped with a 15-foot power cord with built-in transformer. Plug the
power cord into a standard (120V 60Hz) electrical outlet. It will take approximately 10
seconds before you will see the display (this is normal). The water softener is now ready to
be programmed.
