SeQual Eclipse 3 - Standard Components

Personal Ambulatory Oxygen System Users Manual
Step 6: Begin Using Your Eclipse
Breathe normally through the nasal cannula.
NOTE: You will achieve longer operating time on the Battery if you operate your Eclipse
in the Pulse Mode.
Step 7: Universal Cart Operation
The Universal Cart is designed for use on pedestrian-type surfaces.
Align the locator holes on the bottom of the device to the tabs on the Universal Cart.
Press and hold the “ON/OFF” Button for two (2) seconds to power OFF your Eclipse.
Store the Eclipse in a cool and dry location.
Step 8: Power Off the Device
NOTE: DO NOT operate your Eclipse and ambulate while a humidifier is attached.
Remove the humidifier bottle before walking. DO NOT lay the Eclipse down while
attached to a humidifier bottle.
Eclipse Standard Components (Supplied with each Eclipse)
Universal Cart – Your Eclipse can be easily transported while attached to the
Universal Cart.The Universal Cart features wheels and a telescoping handle to
aid mobility.
DC POWER SUPPLY
WARNING:
ONLY USE SEQUAL RECOMMENDED ACCESSORIES. OTHERS MAY IMPAIR PERFORMANCE.
POWER CARTRIDGE
(BATTERY)
AC POWER
SUPPLY WITH
NEMA POWER
CORD
Depress the push-button
on the Universal
Cart handle to
adjust the height
of the handle.
Align the large threaded
screw to the insert at
the back of the Eclipse.
Then hand-tighten the
knob on the cart until
the Universal Cart is
tightly secured to the
device.
UNIVERSAL CART
19
