2
Parts List and Exploded Views
The parts list and exploded views for the Serpent
710 are separate from the Instruction Manual. The
exploded views show all the parts for a particular
assembly step, together with the Serpent part
number. The parts list at the back of this booklet
give the name of the part. Along with all the
Serpent 710 parts used in this car kit, the part
list also contains a list of all option parts for the
Serpent 710, as well as a listing of general items
such as fasteners and promotional items.
Serpent regularly updates the Serpent 710 parts
list and makes it available ‘Downloads’ section
of the 710 product page on myTSN. The Serpent
710 product page can be accessed directly at the
following address:
www.myTSN.com/Serpent710
Be sure to check out the Serpent 710 product page
on myTSN frequently. All information about your
710 can be found there: publications, news items,
set-ups, FAQ’s, images, downloads, videos, and
interesting forums in several languages. myTSN
provides you with an enormous amount of inter-
esting and often valuable information about the
Serpent 710, information provided by Serpent,
its factory and team drivers, and experienced
users around the world. Often this information is
even available in several languages! If you’re not
a member of myTSN.com yet, sign up today and
experience why Serpent excels not only on the
track, but also on the Internet.
Introduction
Contents
PERFORMANCE THROUGH EVOLUTION
Description Page
1. Front Assembly 3
2. Rear Assembly & Differential Assembly 4
3. Shock Assembly 5
4. Bodymount Assembly 5
5. Radio Plate Assembly 6
6. Radio Plate Mounting 7
7. Gearbox Assembly 8
8 Centax Assembly 8
9. Final Assembly 9
10. Parts List 10
