2
Parts list and Exploded views
The parts list and the exploded views for the
Serpent 950R are separate from the Instruction
manual. The exploded views show all the parts
for a particular assembly step, together with the
Serpent part number. In the parts list at the back
of this booklet you will find with the part number
the name of the part. Besides all the Serpent 950R
parts as used in this car kit, you will also find in the
part list all the optional parts for the Serpent 950R,
as well as a listing of general items like fasteners
and promotional items.
Serpent will regularly update the Serpent 950R
parts list and will make it available on the Serpent
950R product page on myTSN, check under
‘Downloads’. This product page can be accessed
directly at the following address:
www.myTSN.com/Serpent950R
Make sure to check out the Serpent 950R product
page on myTSN frequently. All information about
your car can be found here: publications, news
items, set-ups, FAQ’s, images, downloads, video’s
and interesting forums in several languages. MyTSN
provides you with an enormous amount of inter-
esting and often valuable information about the
Serpent 950R, information provided by Serpent, its
factory and team drivers, and experienced users
from around the world. Often this information is
even available in several languages! If you’re not
a member of myTSN.com yet, sign up today and
experience why Serpent excels not only on the
track, but also on the Internet.
Introduction
Contents
PERFORMANCE THROUGH EVOLUTION
Description Page
1. Shock Assembly 3
2. Front Assembly 4
3. Rear Assembly 5
4. Radio Plate Assembly 6
5. Radio Plate Mounting 7
6. Gearbox Assembly 8
7. Centax Assembly 8
8. Final Assembly 9
9. Parts List 10
