Serpent F110 - Page 7

Page
13
8
A
Page
12
7
A
7.1 7.2
7.3
15 mm
13 mm
M3x10
M2.2x6
M3x10
M3x8
M3x6
1
2
Do not fully tighten these screws
yet; fully tighten in step A12
Nylock nut M3
3
4
2
1
5
6
7
Trackrod M3x23 Trackrod M3x26
Approx. 30 mm
Detail view
