Length after assembly
Each step contains a variety of numbers, lines, and symbols. The numbers represent the
order in which the parts should be assembled. The lines and symbols are described below.
Assembly path of one item into another
Group of items (within lines) should be assembled
first
Direction the item should be moved
Glue one item to another
Press/Insert one item into another
Connect one item to another
Gap between two items
Apply transmission grease (Grey), threadlock*
(Blue), CA glue* (Red) or silicone grease (Orange).
(*Items not included.)
Step number; the order in which you should
assemble the indicated parts
USING THE MANUAL
1
SECTION A:
ASSEMBLY INSTRUCTIONS
To Next Page
