Serpent F110 - Chassis and Suspension Assembly

2
Page
7
1
Page
6
A
To prevent the risk of the carbon fibre splitting in the event of a crash you should apply
CA Glue around the chassis’ edge and the power pod plate external and internal edge
as shown in red below.
KIT Bag
1
A
1
2
M3x14
4mm Ride Height spacer
(rubber tyres).
Nylock Nut M3 Low Alu
CA Glue
