Serpent F110 - Page 5

4
A
Page
9
Page
8
3
A
M3x16
M3x16
4.1
4.2
M3x6
M3x6
M3x6
1
2
Use the following servo
saver insert with this
brand of servos:
23 - Sanwa / KO / JR
24 - Hitec
25 - Futaba (default)
4.4
Nylock nut M3
Nylock nut M3
3x6x0.5
3x6x0.5
3x7x7
NOT INCLUDeD
NOTE: It is needed to remove the servo
holes of the bottom part of the servo
before going onto the step 4.4.
4.3
NOT INCLUDeD
