Serpent Viper 988e - Step 10: Rear Drivetrain Components

bag 3
10
STEp 10
10.1
10.2
10.3
1- Note orientation of the
outside wheel axle shim.
2- Note position of the
lever spring.
12x15x0.25
12x18x1 Conical 12x18x4
M3x4
3x22
12x18x4
12x15x0.25
12x18x4
2.5x12
M3x4
3x22
1
1
3
4
5
2
2
2.5x12
