12
Position and tail lamp is working. It can be pulled out the ignithion key arm this position.
Notice: when you leave the motorcycle please take the key away and lock the steering handlebar.
Handlebar Control System
I. Clutch Lever
Grip this lever to disengage the driving system at the time of starting the engine or shifting the gear. Disengage the clutch by grasping the lever.
2. Handle
3. Horn Button
Press this button to make the horn sound.
4. Turn signal switch
Sliding the switch to the — position will flash the left turn signal.
Moving the switch to the — position will flash the right turn signal. & Dimmer switch
When the switch is pushed up to the “•13” position,the high beam will be lit; When the switch
is pushed down to the “*” ,the low beam will be lit.
6. The headlamp sparking switch
Press it then the high beam lamp is lighted,loosen it the lamp is out. Which is used for overtaking.
