28
Letter Description MD-150 MD-175 MD-200/250 MD-250-36
A
Unit Width 22” 24” 30” 36"
B
Unit Depth 30 1/2" 30 1/2" 30 1/2" 30 1/2"
C
Outside Ice Bin Depth 22" 22 1/2" 22 1/2" 22 1/2"
D
Under Unit Width 18" 20" 26" 32"
E
Under Unit Depth 20 1/2" 20 1/2" 20 1/2" 20 1/2"
F
Recommended countertop Cut-out* 3"x13" 3"x14" 3"x18" 3"x18"
G
Maximum Countertop Cut-out* 18"x20 1/2" 20"x20 1/2" 26"x20 1/2" 32"x20 1/2"
OPERATION
MD SERIES COUNTERTOP MEASUREMENTS
CAUTION:
*Cutting the countertop may decrease its strength. Counter should
be braced to support the dispenser countertop weight plus ice storage ca-
pacity and weight of icemaker, if applicable.
