SET 1501 H - Page 9

9
Product description: Overall description
Pos. Part Illustration
1 LED lamp
2 Control panel
(behind a cover)
3 Drip tray
4 Cable groove
(for accessory only)
5 Wall bracket
6 Mains electricity
connection
(behind the lid)
7 Air outlet
8 Humidity sensor
9 Air inlet
10 Water drain
SET (H)
Presentation
Fig. 3
1
Front cover
9
Rear view
7
5
8
3
2
4
Inside (front cover removed)
9
10
Bottom view
en
