Setec Power DC Quick EV Charger - General Specifications

6
GENERAL SPECIFICATION
Item
Specifications
Remark
Rated voltage
3 phase 380VAC/single phase220VAC
Voltage fluctuation range
380V /220V +/- 10%
Number of phases
Three-phase and four-line +PE
Rated frequency
50 or 60 Hz
AC Input
Frequency fluctuation range
+/- 5%
Input power factor
0.99
In rated operation
Input power
20kw +10%
Grounding detection
30mA
Harmonic current
Total 5% or less
Rated Output Capacity
20kw
DC Output
Voltage variable range
50 to 500VDC
Output current
40ADC
Current variable range
0 to 40A
Efficiency
96% or more
Ripple current
6.0Ap-p or less
Degree of Protection IP
IP54
Better use waterproof shed
Ambient temperature
-20 ℃ ~ 55℃
Structure
Storage temperature
-30℃ ~ 70 ℃
Chassis dimensions LxWxH
715*500*274mm
Package Weight
100KG( by air)
Include 2 plugs and cables and modules
Certification
CE/IEC 61851
Safety
Emergency stop button
Vehicle connector
CHAdeMO+CCS
OTHERS
Battery communication protocol
CAN / PLC
Management system
OCPP 1.6
Network communication
WIFI, Ethernet
4G (optional)
Cooling method
Force air cooling
