Controller Signal
No. Functions
1 External Zero
2
3 Power Common
4 Set
5 Valve Drive
6 Signal Common
7 Flow Readout
8 GND
9
10
11 -15V
12 -15V
13
14 Common
15 +15V
Signals Instruction of Table 2:
① Necessary signals:±15V, Power Common, Set, Flow
Output and Signal Common. These signals must be
connected correctly.
② “Valve Drive” and “ External Zero Adjustment”
signals are only for D07 series MFC products. For
other MFC products, please do NOT connect
③
GND Line normally is disconnected. (Please refer to
the MAINTENANCE information)
④ For MFM, “Valve Drive ”and “Set” is invalid.
⑤ If you provide your own cable for other MFC products,
we suggest that you only connect necessary signals as
in ①.
