5.3 External Control Connection
For External Control Connection, please refer to Table 3. PC or other external control equipments can control the
MFC by external control connector.
Table 3. External Control Connection
a. D08-2F
External Control Signal
No. Functions
1 +5.00V
2 Signal Common
3 External SetⅠ
4 External SetⅡ
5
6
7 Flow ReadoutⅠ
8 Flow ReadoutⅡ
9
10
11 Valve OverrideⅠ
12 Valve OverrideⅡ
13
14
15
b. D08-3F
External Control Signal
No. Functions
1 +5.00V
2 Signal Common
3 External SetⅠ
4 External SetⅡ
5 External SetⅢ
6
7 Flow ReadoutⅠ
8 Flow ReadoutⅡ
9 Flow Readout Ⅲ
10
11 Valve OverrideⅠ
12 Valve OverrideⅡ
13 Valve Override Ⅲ
14
15
c. D08-4F
External Control Signal
No. Functions
1 +5.00V
2 Signal Common
3 External SetⅠ
4 External SetⅡ
5 External SetⅢ
6 External Set Ⅳ
7 Flow ReadoutⅠ
8 Flow ReadoutⅡ
9 Flow Readout Ⅳ
10 Flow Readout Ⅲ
11 Valve OverrideⅠ
12 Valve OverrideⅡ
13 Valve Override Ⅲ
14 Valve Override Ⅳ
15
