E.3 Tanks according to DIN 6618 T2: 1989 and tubs with vaulted base and the
same dimensions
Diameter
[mm]
Height
[mm]
Max. density of the product stored
[kg/dm
3
]
VL 34
VL 230
VL 255
VL 330
VL 410
VL 500
VL 570
1600
 2 820
 1.9
 1.9
 1.9
 1.9
 3 740
 1.6
 1.9
 1.9
 1.9
 5 350
 1.6
 1.9
 1.9
 1.9
 6 960
 1.6
 1.9
 1.9
 1.9
2000
 5 400
 1.4
 1.9
 1.9
 1.9
 6 960
 1.4
 1.9
 1.9
 1.9
 8 540
 1.4
 1.9
 1.9
 1.9
2500
 6 665
 1.0
 1.9
 1.9
 1.9
 8 800
 1.0
 1.9
 1.9
 1.9
2900
 8 400
 0.9
 1.9
 1.9
 1.9
 9 585
 0.9
 1.9
 1.9
 1.9
 12 750
 0.8
 1.2
 1.2
 1.6
 15 950
-
 1.0
 1.0
 1.2
E.4 Series of interstitial spaces in battery tanks
 From Messrs Berolina Polyester GmbH & Co. KG according to General Approval No. Z-
40.11-165 from the Building Inspection Authorities.
