APPENDIX TD
VACUUM LEAK DETECTOR VL(R) ..
05/02/2018
- TD-1 -
Technical data
1. Electrical data
Electrical supply (without external signal) 230 V, 50 Hz, 50 W
24 VDC, 50 W
Switch contact load, terminal strips AS (5 and 6) 230 V max: 230 V, 50 Hz, 200 VA
min: 20 mA
24 VDC max: 24 VDC, 1 A
Switch contact load, dry relay contacts max: 230 V, 50 Hz, 3 A
(terminals 11, 12 and 13) min: 6 V / 10 mA
External fuse for the leak detector max. 10 A
Overvoltage category 2
Protection type of housing, Plastic IP 30
Implementation VL …/p (sheet steel) IP 54
2. Pneumatic data (requirements concerning the test measuring gauge)
Nominal size min. 100
Accuracy class min. 1.6
Scale end value -600 mbar / -1000 mbar
