See “DMX protocol” on page 39 for detailed DMX protocols, or visit www.sgmlight.com
11 channel RAW 16 channel 16 bit (calibrated)
MSB LSB Name MSB LSB Name
1 Shutter 1 Shutter
2 Intensity 2 3 Intensity
3 CTC 4 CTC
4 Red PANEL 1 5 6 Red PANEL 1
5 Green PANEL 1 7 8 Green PANEL 1
6 Blue PANEL 1 9 10 Blue PANEL 1
7 White PANEL 1 11 12 Red PANEL 2
8 Red PANEL 2 13 14 Green PANEL 2
9 Green PANEL 2 15 16 Blue PANEL 2
10 Blue PANEL 2
11 White PANEL 2
