PAGE 63
SPECIFICATION
b) Brush cutter & edge trimmer
Cutting device Metal blade Nylon wire
Cutting device 3-teeth metal blade Nylon thread spool
Cutting device dimensions = 255 x 25,4 x 1,6mm 2 threads x
2.5m x 2.4mm
Cutting diameter = 255mm to 410mm
Blade rotation direction Counterclockwise (from operator’s view)
Cutting device max rotation speed at max engine speed
Metal blade: 7100 min-1 Nylon thread: 6600 min-1
Dry weight with attachment 6.9kg approx. 6.2kg approx.
Pole pruner and Hedge trimmer
Chain and Guide bar 12” (300mm)
Blade holder 390mm
Cutting length 300mm
Blade spacing 19mm
Chain : 44 teeth; Gauge 0,050”; Pitch 3/8”
Chain no load speed 15 m/s
Max cutting diameter Branches ≤ 5mm
Oil tank 150cm3
Working angle adjustment From 90° to 270°
Dry weight with attachment 8.4kg approx.
Dry weight with attachment 8.9kg approx.
