SETTING UP
The Shadow Dusk should be located on a secure, solid surface such as the floor. The machine can oper-
ate in any orientation from 45 degrees upwards to 45 degrees downwards. Take precautions to avoid
fluid spills if the machine is oriented at an angle.
Fluid Set Up
Only use genuine Tempest Smoke Simulations fluids in your Dusk machine. The use of any other fluid will void
your warranty, may damage the equipment, and may cause health hazards. For convenience, the Dusk is
designed with an integral compartment that will hold a 1-Litre bottle of fog fluid. Place the fluid bottle
into the compartment. Feed the fluid inlet hose into the bottle of fog fluid, insuring that the filter, locat-
ed at the end of the tube, is fully submerged in fluid. Slide the bottle cap along the tube and tighten the
cap onto the bottle. Take precautions to avoid fluid spills.
Remote Connection
Plug the remote control into the socket on the rear of the machine marked “Remote Control”. The re-
mote control for the Dusk is unique to this machine and is not compatible with other Tempest Shadow
smoke machines.
Power Connections
Ensure that the machine is plugged into an outlet rated for the proper voltage and amperage. The
Dusk is a 1,000 watt device and will draw 4.3A at 230 VAC or 9.1A at 115 VAC. Note: 230 volt machines are
shipped with bare leads at the end of the power cord. A proper electrical connector must be attached based
on the local power requirements. If unsure how to do this, please contact Tempest for assistance. An example
of properly wiring a UK 13A connector is shown below.
Earth Wire
Neutral Wire
Outer Insulation
Live Wire
Fuse
Cable grip
