Shanling EM7 - Names of Parts

/AC IN
交流输 入
USB AUDIO
USB DAC
ETHERNET
COAXIAL OPTICAL
R
LRCA
R
L
XLR
COAXIAL OPTICAL
DIGITAL
IN
ANALOG OUT
DIGITAL OUT
~220V-240V/50Hz
S
tr
eam
in
g M
u
s
ic C
e
ntr
e E
M7
8
Names of Parts
EM7
Streaming Music Centre
5.8 Inch Touch Screen (1080 x 920)1
Micro SD Card Slot
Power Indicator
XLR Balanced
4.4mm Balanced
6.35mm Single Ended Headphone Output3 5mm Single Ended
Headphone Output
.
Power Button / Volume Wheel / Lock Button
USB DAC Input
Digital Optical Input
Digital Coaxial Input
Wired Network Connection
USB for Connecting External Disk
USB for Digital Audio Output; USB for Connecting External Disk
Balanced Audio Output
Analog Output
Digital Coaxial Output
Digital Optical Output
Power Connector
Note: Display adjustment limited to 60 degree angle.
Power Switch
