Output power: 2V @ 32Ω ( 125mW @ 32Ω )
Frequency response: 20Hz - 50kHz ( -0.5dB )
THD+N: 0.0008% @ 32Ω ( A-Weighting @ 0.5V )
Dynamic range: 122dB @ 32Ω ( A-Weighting )
Signal to noise ratio: 121dB @ 32Ω ( A-Weighting )
Channel separation: 76dB @ 32Ω
Output impedance: <0.8Ω
Specifications and parameters
3.5mm Headphone Output
Output power: 2.5V @ 32Ω ( 195mW @ 32Ω )
Frequency response: 20Hz - 50kHz ( -0.5dB )
THD+N: 0.0008% @ 32Ω ( A-Weighting @ 0.5V )
Dynamic range: 120dB @ 32Ω ( A-Weighting )
Signal to noise ratio: 116dB @ 32Ω ( A-Weighting )
Channel separation: 109dB @ 32Ω
Output impedance: <1.6Ω
Size: 54 x 18 x 9mm
Weight: about 12.6g
2.5mm Balanced Headphone Output
