Shark NV370 - Maintenance and Blockage Checks (Cont.); Hose and Connection Blockage Check; Motorized Floor Brush Blockage Check

1-800-798-7398
20
4 Hose and Connections to Vacuum
• Detach the stretch hose from the back of the
portable Lift-Away
®
canister by squeezing
the tabs together and pulling up. (Fig. 28)
Straighten out the hose and look inside for
blockages.
• Remove the dust cup and extension wand and
separate the portable Lift-Away
®
canister from
the motorized floor brush. Look in all 4 openings
for any blockages. (Fig. 29)
5 Motorized Floor Brush
(Side suction models)
• Detach the hose on the motorized floor brush
at the top by squeezing the tabs together and
pulling out, and at the bottom by pulling out the
connector. Inspect inside the 3 holes. (Fig. 30)
(Center suction models)
• Turn motorized floor brush over and detach the
hose by squeezing the tabs together and pulling
it out. Straighten out the hose and inspect the
inside for any blockages. (Fig. 31)
Maintenance - cont’d
Fig. 31
Fig. 30
Fig. 29
Fig. 28
