WHAT’S IN THE BOX YOU JUST
OPENED:
A Vacuum Body
B Floor Power Nozzle
C Handle Assembly
D Super Stretch Hose
E Cleaning Wand with Handle
F Cleaning Wand
G Pet Hair Power Brush
H Cleaning Attachments
I 16” Crevice Tool*
J Accessory Bag (not shown)
* Note: The crevice tool may be
stored in the Cleaning Wand.
Getting Started
Your Shark
®
Navigator
™
Professional is easy to
assemble:
1 Lay your vacuum body on a
level surface.
2 Slide the electrical connection
from the power nozzle into the
main body to click into place.
3 Connect the hose from the main
body to the power nozzle; push
with a slight turning motion to
create a snug fit.
4 Slide the handle assembly
into the upright unit aligning
the hose hook on the handle
assembly with the power cord
hooks on the back of the unit.
5 Secure the handle assembly in
place with included nut/bolt
(shipped attached to handle
assembly).
6 Place the vacuum in the upright
position.
7 Insert the Cleaning Wand with
the Handle into the center post
on the tool caddy. Insert the
16" Crevice Tool onto the post
in front.
8 Store the Crevice Tool, Dusting
Brush on the back of the unit.
Store the Cleaning Wand onto
the back post of the tool caddy.
A
C
E
H
I
B
G
D
F
8
4
5
3
7
2
