Sharp 1640L - Page 41

40
Figure 9
Figure 10
Figure 13
Figure 17
Oil-in Hole
Spindle Bearing
Adjust.
3
1
2
1. Loosen 3 screws
2. Tighten 3 screws on the side as needed
(First take off chasing dial assembly.)
3. Make sure to test the up/down movement of
halfnuts/holders before reassembling
