36
FOLLOW REST ASSEMBLY
Item No.
Part Name
Amt. Used
Type: 17
Part No.
Type: 19
Part No.
1
Body-follow rest
(Bronze tip type)
1
10035019409
1003503107
(Roller type)
1
100352700
100352710
2
Nut-lead screw
2
3
Lead-screw
2
4
Collar
2
5
Pin , 4x25L
2
6
Plug-lead screw
2
7
Screw-hexa. socket headless cap,
M8xP1.25x10L
4
8
Shoe
2
9
Screw-hexa. Socket head cap,
M10xP1.5x30L
2
10
Washer
2
