20
APRON ASSEMBLY
Item No.
Part Name
Amt. Used
Type: 16
Part No.
Type: 18
Part No.
114
Seat-switch
1
1210701706
1210701706
115
Key-square , 6x8x25L
1
116
Hexagon socket screw ,
M8xP1.25x16L
2
117
Bracket
1
1210701804
1210701804
118
Screw-lock
2
1210701902
1210701902
119
Screw-hexa. socket headless cap,
M8xP1.25x8L
1
1210702007
1210702007
120
Seat-lever
1
1210702105
1210702105
121
Set screw , M8xP1.25x8L
2
91120808
91120808
122
Spring
1
123
Lever
1
1210702203
1210702203
124
Sleeve-lever
1
1122103601
1122103601
