23
PICTURE TUBE
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK : SPARE PARTS-DELIVERY SECTION
' MARK : X- RAY RELATED PARTS
20MU11
çåV101VB48JLL40X/*SMPicture TubeCC
çåDY601RCILH0105GJZZ MDeflection YokeAY
åL702RCILG0099PEZZ MDegaussing Coil
PMAGF3045CEZZ JMagnet Ass'yAK
QEARC2016PEZZRGrounding Part
20MU11
çå V101 VB48KRD89X/3E M Picture Tube
çå DY601 RCiLH0100MEZZ M Deflection Yoke AZ
åL702RCILG0099PEZZ MDegaussing CoilAM
MSPRT0002MEZZMSpring for CRTAA
(20MU11)
PMAGF3046CEZZ JMagnet Ass'yAK
QEARC2016PEZZ R Grounding Part
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-ADUNTK9529WEX7 –MAIN Unit (20MU11)—
PWB-ADUNTK9532WEX0 –MAIN Unit (20MU11) —
PWB-BDUNTK9530WEW6–CRT Unit (20MU11)
PWB-BDUNTK9533WEV4–CRT Unit (20MU11,—
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDETLY
åTU51 VTUVTST5UF670 MTuner
INTEGRATED CIRCUITS
IC101 VHIKA78L05B-1+ J KA78L05B AD
çåIC201RH-iX3253CEZZJTA1268ANAV
IC351VHiTDA7233/-1JTDA7233AF
åIC501VHiTA8403K/-1JTA8403KAL
çåIC701VHiSTR301301EJSTR30130AP
åIC751VHiKA7809AP-1 RKA7809AP AE
åIC761VHiKA7812Pi-1RKA7812PIAE
IC2001RH-IX3297CEZZ JTMPA8701CMF142AX
IC2040VHiPST994C/-1JPST994CAD
IC2101VHIBR24C02/-1 JBR24C02 AF
TRANSISTORS
You can substitute "VS2SC2462-C-1" for "VS2SD601AR/-1".
Q201VS2SC2735//1EJ2SC2735AC
Q351 VS2SD601AR/-1 J 2SD601AR AC
Q401VS2SD601AR/-1J2SD601ARAC
Q403VS2SD601AR/-1J2SD601ARAC
Q404VS2SB709AR/-1J2SB709ARAC
Q451VS2SB709AR/-1J2SB709ARAC
Q501VS2SD601AR/-1J2SD601ARAC
Q601VS2SC2655Y/-1J2SC2655(Y)AE
åQ602VS2SD2586//1EJ2SD2586AM
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
PWB-A: DUNTK9529WEX7 (20MU11)
MAIN UNIT
20MU11
