Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
25
C352 VCEA0A1CW107M J 100 16V EL. AC
C353 VCEA0A1CW337M J 330 16V EL. AC
C354 RC-QZA104TAYK J 0.1 50V Mylar AB
C355 VCEA0A1CW226M J 22 16V EL. AB
C361 VCEA0A1CW477M J 470 16V EL. AC
C362 VCEA0A1CW476M J 47 16V EL. AB
C403 VCCCCY1HH101J J 100p 50V Ceramic AA
C404 VCCCCY1HH680J J 68p 50V Ceramic AA
C405 VCEA0A1HW335M J 3.3 50V EL. AB
C406 VCEA0A1HW335M J 3.3 50V EL. AB
C407 RC-QZA104TAYK J 0.1 50V Mylar AB
C408 VCEA0A1CW106M J 10 16V EL. AB
C409 VCEA0A1HW105M J 1.0 50V EL. AB
C410 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C411 VCEAGA1CW108M J 1000 16V EL. AD
C413 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C414 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C419 VCCCCY1HH330J J 33p 50V Ceramic AA
C420 VCCCCY1HH471J J 470p 50V Ceramic AA
C451 RC-QZA563TAYK J 0.056 50V Mylar AB
C454 VCEA0A1HW475M J 4.7 50V EL. AB
C502 VCEA0A1EW477M J 470 25V EL. AD
C504 VCKYPA2HB391K J 390p 500V Ceramic AA
C505 VCQYTA1HM473K J 0.047 50V Mylar AB
C507 VCKYPA1HB102K J 1000p 50V Ceramic AA
C508 VCEAGA1VW107M J 100 35V EL. AC
C509 VCKYPA2HB102K J 1000p 500V Ceramic AA
C510 VCEAGA1VW477M J 470 35V EL. AD
C511 VCQYTA1HM473K J 0.047 50V Mylar AB
C513 VCEACA1HC225M J 2.2 50V EL. AC
C514 VCEACA1HC225J J 2.2 50V EL. AC
C517 VCKYCY1HB102K J 1000p 50V Ceramic AA
C522 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C551 VCSATA1CE225K J 2.2 16V Tantalum AB
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C604 VCEA0A1CW227M J 220 16V EL. AC
çå C608 VCFPPD3CA772H J 7700p 1.6kV M-Poly. AF
C609 RC-QZA223TAYK J 0.022 50V Mylar AB
C612 VCFPPJ2EB474J J 0.47 250V M-Poly. AF
C631 VCEA0A1HW225M J 2.2 50V EL. AB
C632 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C633 VCEA0A1HW105M J 1.0 50V EL. AB
C652 VCEA0A1HW475M J 4.7 50V EL. AB
C653 VCEA0A1CW106M J 10 16V EL. AB
C661 VCKYPA2HB152K J 1500p 500V Ceramic AA
C662 VCEA0A1CW477M J 470 16V EL. AC
å C701 RC-FZ027SCEZZ J 0.047 AC125V Plastic
C702 VCKYPB2HE103P J 0.01 500V Ceramic AB
C703 VCKYPB2HE103P J 0.01 500V Ceramic AB
C704 VCKYPB2HE103P J 0.01 500V Ceramic AB
åC705RC-EZ0718CEZZ J470200VEL.
å C706 RC-KZ0092GEZZ J 3300p AC125V Ceramic AC
C707 VCEAGA2CW226M J 22 160V EL. AD
å C712 RC-EZ0638CEZZ J 33 160V EL. AG
C751 VCEA0A1VW477M J 470 35V EL. AB
C754 VCEA0A1CW337M J 330 16V EL. AC
C755 VCEA0A1CW107M J 100 16V EL. AC
C756 VCEAGA1CW108M J 1000 16V EL. AD
C757VCQYTA1HM104J+ J0.150VMylarAB
åC758VCEA0A2EW106M+J10250VEL.AC
C760VCEA0A1CW108M+J100016VEL.AD
C801VCQYTA1HM223J+ J0.02250VMylarAB
C802VCEA0A1HW474M+J0.4750VEL.AB
C803VCCCCY1HH120J* J12p50VCeramicAA
C804 VCEA0A1HW104M J 0.1 50V EL. AB
C805 VCEA0A1HW104M J 0.1 50V EL. AB
C806 VCEA0A1HW104M J 0.1 50V EL. AB
C807 VCCCCY1HH820J J 82p 50V Ceramic AA
C901 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C905 VCEA0A1HW335M J 3.3 50V EL. AB
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2021 VCCCCY1HH101J J 100p 50V Ceramic AA
C2022 VCCCCY1HH101J J 100p 50V Ceramic AA
C2023 VCCCCY1HH101J J 100p 50V Ceramic AA
C2024 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1.0 50V EL. AB
C2051 VCCCCY1HH101J J 100p 50V Ceramic AA
C2060 RC-QZA104TAYK J 0.1 50V Mylar AB
C2061 VCKYD41HB101K J 100p 50V Ceramic AA
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2402 VCCCCY1HH560J J 56p 50V Ceramic AA
C2601 VCEA0A1HW475M J 4.7 50V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ17 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ18 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ19 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ21 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ23 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ24 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ26 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ31 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ32 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ35 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ39 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ40 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ46 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ49 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ52 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ54 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ55 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ57 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ59 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ62 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ63 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ66 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ67 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ68 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ69 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ71 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ75 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ77 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ78 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ79 VRS-CY1JF000J J 0 1/16W M-Ox. AA
å R51 VRS-VV3AB331J J 330 1W M-Ox. AA
å R52 VRS-VV3DB470J J 47 2W M-Ox. AA
å R53 VRS-VV3LB223J J 22k 3.0W M-Ox. AB
R54 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R55 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R56 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R57 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
PWB-A: DUNTK9529WEX7 (20MU11)
MAIN UNIT (Continued)
20MU11
