Ref. No.Part No.★DescriptionCodeRef. No.Part No.★DescriptionCode
27
R2064VRD-RA2BE332JJ3.3k1/8WCarbonAA
R2066VRS-CY1JF103JJ10k1/16WM-Ox.AA
R2067VRS-CY1JF103JJ10k1/16WM-Ox.AA
R2068VRS-CY1JF103JJ10k1/16WM-Ox.AA
R2070VRS-CY1JF103JJ10k1/16WM-Ox.AA
R2101VRS-CY1JF101JJ1001/16WM-Ox.AA
R2102VRS-CY1JF101JJ1001/16WM-Ox.AA
R2401VRS-CY1JF101JJ1001/16WM-Ox.AA
R2402VRS-CY1JF101JJ1001/16WM-Ox.AA
R2403VRS-CY1JF101JJ1001/16WM-Ox.AA
R2404VRS-CY1JF101JJ1001/16WM-Ox.AA
R2501VRS-CY1JF123JJ12k1/16WM-Ox.AA
R2503VRS-CY1JF273JJ27k1/16WM-Ox.AA
R2504VRS-CY1JF123JJ12k1/16WM-Ox.AA
R2505VRS-CY1JF563JJ56k1/16WM-Ox.AA
R2506VRS-CY1JF563JJ56k1/16WM-Ox.AA
R2507VRS-CY1JF823JJ82k1/16WM-Ox.AA
R2508VRS-CY1JF153JJ15k1/16WM-Ox.AA
R2509VRS-CY1JF272JJ2.7k1/16WM-Ox.AA
R2601VRD-RA2BE331JJ3301/8WCarbonAA
SWITCHES
S2501QSW-K0202PEZZ+ JPowerAB
S2502QSW-K0202PEZZ+ JVol-DownAB
S2503QSW-K0202PEZZ+ JVol-UpAB
S2504QSW-K0202PEZZ+ JCH-DownAB
S2505QSW-K0202PEZZ+ JCH-UpAB
MISCELLANEOUS PARTS
åRY701RRLYU0036CEZZJRelayAM
åF701QFS-B4023CEZZJFuse, 4A(125V)AC
FB602 RBLN-0037CEZZ J Ferrite Bead AB
FB603 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702QFSHD1014CEZZJFuse HolderAC
J903QJAKE0211CE09 JJack, Audio InAF
J905QJAKE0211CE04 JJack, Video InAF
P302 QPLGN0261CEZZ J Plug, 2-pin (S) AB
P401 QPLGN0561CEZZ J Plug, 5-pin (GBN) AB
P601 QPLGN0603CEZZ J Plug, 6-pin (K) AB
P651 QPLGN0361CEZZ J Plug, 3-pin AB
P701QPLGN0260CEZZ JPlug, 2-pin (M)AA
P751QPLGN0461CEZZJPlug, 4-pin (YBN)AB
P2001 QPLGN0561CEZZ J Plug, 5-pin AB
RMC2601 RRMCU0230CEZZ JR/C ReceiverAK
HM601 LX-GZ3002PEZZ R Screw AB
HM602 LX-GZ3002PEZZ R Screw AB
HM705 LX-GZ3001PEZZ R Screw AB
HM706 LX-GZ3001PEZZ R Screw AB
HM707 LX-GZ3001PEZZ R Screw AB
HM708 LX-GZ3001PEZZ R Screw AB
HM711 LX-GZ3001PEZZ R Screw AB
HM712 LX-GZ3001PEZZ R Screw AB
HM713 LX-GZ3001PEZZ R Screw AB
HM714 LX-GZ3001PEZZ R Screw AB
HM715 LX-GZ3001PEZZ R Screw AB
HM716 LX-GZ3001PEZZ R Screw AB
HM717 LX-GZ3001PEZZ R Screw AB
HM718 LX-GZ3001PEZZ R Screw AB
HM719 LX-GZ3001PEZZ R Screw AB
HM720 LX-GZ3001PEZZ R Screw AB
HM722 LX-GZ3002PEZZ R Screw AB
HM724 LX-GZ3002PEZZ R Screw AB
HM726 LX-GZ3002PEZZ R Screw AB
HM729 LX-GZ3001PEZZ R Screw AB
HM730 LX-GZ3001PEZZ R Screw AB
HM734 LX-GZ3002PEZZ R Screw AB
HM735 LX-GZ3002PEZZ R Screw AB
HM739 LX-GZ3002PEZZ R Screw AB
HM740 LX-GZ3002PEZZ R Screw AB
HM741 LX-GZ3002PEZZ R Screw AB
HM742 LX-GZ3002PEZZ R Screw AB
HM743 LX-GZ3002PEZZ R Screw AB
RDA501 PRDAR0103GJFW X Heat Sink, for IC501 AN
RDA602 PRDAR0216PEFW R Heat Sink, for Q602 AE
RDA701 PRDAR0238PEFW R Heat Sink, for IC701 AN
TP701 QLUGP0102PEZZ R Lug AA
PZETM0016CEZZ J Insulator AB
LX-BZ3049GEFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-TZ3004CEFD J Screw AA
PWB-A: DUNTK9529WEX7 (20MU11)
MAIN UNIT (Continued)
20MU11
