21F-PD250 / 21F-PT220 / 21F-PA18 / 21F-PA18(B)
3 – 5
SHIPPING SETTING & CHECKING
(1) The following default data has been factory-set for the E2PROM follow by INITIAL DATA selected.
ITEMS DATA SETTING MODEL
LAST POWER ON
LAST TV/AV MODE TV MODE
LAST POSITION CH 1
FLASHBACK CHANNEL CH 1
1/2 DIGITENTR 2 DIGIT ENTRY
VOLUME 0 (Min)
BLUE BACK OFF
CHILD LOCK OFF
OFF TIMER --:--
PASSWORD 0000
AFT ALL CH ON
COLOR SYSTEM ALL CH AUTO
SKIP ALL CH OFF
CONTRAST 60
COLOR +6
BRIGHTNESS 0
TINT 0(CENTER)
SHARPNESS +6
WHITE TEMP 0
INITIAL LANGUAGE SOUND SYSTEM
9 (HEX EE) THAI B/G
FACTORY SETTING BY MODEL
(Reference: Geomagnetism Adjustment)
MODEL MAGNETIC FIELD(V, H) nT BACKGROUND LANG. S-SYS LANG QTY
THAI 20,000 40,000 12300°K THAI B/G 2
2: ENGLISH / THAI
*NOTE FOR OSD TYPE:
**This magnetic filed is in ITC CRT specification.
ALL MODELS
SOUND SYSTEM B/G
