21S-FX10L
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
P302 QPLGNA109WJZZ AB R Plug ,4Pin(S)
P601 QPLGN0660CEZZ AC R Plug ,6Pin(F)
P602 LHLDW1104PEZZ AB R Plug
P701 QPLGN0260CEZZ AC R Plug ,2Pin(M)
P702 QPLGN0269GEZZ AB R Plug ,2Pin
P1001 LHLDW1105PEZZ AB R Plug
P1002 QPLGNA110WJZZ AB R Plug ,5Pin(BC)
RMC1001 RRMCUA022WJZZ AG R Remote Receiver
RDA301 PRDARA418WJFW R Heat Sink for IC301
RDA392 PRDARA181WJFW R Heat Sink for IC392
RDA501 PRDARA759WJFW AD R Heat Sink for IC501
RDA602 PRDARA361WJFW R Heat Sink for Q602
RDA605 PRDARA361WJFW R Heat Sink for Q605
RDA701 PRDARA119WJFW AF R Heat Sink for IC701
RDA751 PRDARA167WJFW R Heat Sink for IC751
TP801 QPLUGP0111GEFW R Plug
[4] CRT UNIT
Q853 RH-TX0110BMZZ+ AC R TX0110
Q854 RH-TX0110BMZZ+ AC R TX0110
Q855 RH-TX0110BMZZ+ AC R TX0110
Q894 VS2SA1530AR-1Y AB R 2SA1530AR
D859 VHDHSS4148+-1Y AA R Diode
D896 VHEZJ5R6C++1EY AA R Zener Diode , 5.6V
D898 VHDHSS4148+-1Y AA R Diode
JB418 QJUM-0001AJFWY R Jumper Wire
L851 VP-MK820K0000+ AB R Peaking 82μH
C851 VCKYPA1HB821K+ AA R 820p 50V Ceramic
C852 VCKYPA1HB561K+ AB R 560p 50V Ceramic
C853 VCKYPA1HB561K+ AB R 560p 50V Ceramic
C880 RC-KZ0016CEZZ AC R 10000p 1.5KV Ceramic
C893 VCEA0A1CW336M+ AB R 33 16V Electrolytic
R849 VRS-CY1JF271JY AA R 270 1/16W Metal Oxide
R850 VRS-CY1JF470JY AA R 47 1/16W Metal Oxide
R851 VRS-CY1JF470JY AA R 47 1/16W Metal Oxide
R852 VRS-CY1JF470JY AA R 47 1/16W Metal Oxide
R854 VRS-CY1JF271JY AA R 270 1/16W Metal Oxide
R855 VRS-CY1JF271JY AA R 270 1/16W Metal Oxide
R859 VRS-RG3DB153J+ AB R 15K 2W Metal Film
R861 VRS-RG3DB153J+ AB R 15K 2W Metal Film
!
R863 VRS-RG3DB153J+ AB R 15K 2W Metal Film
!
R864 VRD-RA2BE470JY AA R 47 1/8W Carbon
!
R876 VRS-CY1JF121JY AA R 120 1/16W Metal Oxide
R877 VRS-CY1JF121JY AA R 120 1/16W Metal Oxide
R878 VRS-CY1JF121JY AA R 120 1/16W Metal Oxide
R880 VRD-RM2HD332JY AA R 3.3K 1/2W Carbon
R881 VRD-RM2HD332JY AA R 3.3K 1/2W Carbon
R882 VRD-RM2HD332JY AA R 3.3K 1/2W Carbon
R891 VRS-CY1JF152JY AA R 1.5K 1/16W Metal Oxide
R892 VRS-CY1JF391JY AA R 390 1/16W Metal Oxide
R894 VRS-CY1JF152JY AA R 1.5K 1/16W Metal Oxide
R895 VRD-RA2BE561JY AA R 560 1/8W Carbon
P860 LHLDW1104PEZZ AB R Plug 4Pin (H)
P880 LHLDW1105PEZZ AB R Plug 5Pin (K)
SC851 QSOCVA023WJZZ AE R Socket , 12Pin
SP301
!
ACC701 QACCZA091WJPZ R AC Cord
VSP9050PA05YA AH R SPEAKER
QCNW-G288WJPZ R SP WIRE (+--+)
QCNW-A292WJZZ AD R H-WIRE
QCNW-A721WJZZ AD R K-WIRE
[5] SUPPLIED ACCESSORIES
RRMCGA571WJSA R Infrared Remote Control Unit
TINS-D896WJZZ R Operation Manual
UBATUA017WJZZ R Battery
[3] MAIN UNIT
