Sharp 21S-FX10L - Service Mode

21S-FX10L
4 – 4
Setting Mode Items
Data Service Mode Range Default Data
F01 ABCL-Gain 0/1 0
F02 SHP-AV-PRE -16~+16 0
F03 SHP-YUV-PRE -16~+16 0
F04 SHP-P-PRE -31~+31 0
F05 SHP-N3-PRE -31~+31 0
F06 SHP-AV-OVER -16~+16 0
F07 SHP-YUV-OVER -16~+16 0
F08 SHP-P-OVER -31~+31 0
F09 SHP-N3-OVER -31~+31 0
F10 SHP ANT-ON II OFFSET -15~0 -10
F11 RGB-CLIP 0/1 0
F12 E-SAVE 0~63 30
0~127 (O20=0) 120
0~255 (O20=1) 246
F14 VIF-G 0~7 5
F15 YDL-TV 0~7 5
F16 YDL-TV-P 0~7 5
F17 YDL-TV-N3 0~7 5
F18 YDL-AV 0~7 5
F19 YDL-AV-P 0~7 5
F20 YDL-AV-N3 0~7 5
F21 YDL-YU
V 0~7 0
F22 TINT-AV -32~+32 6
F23 COL-AV -32~+32 0
F24 COL-P -31~+31 24
F25 COL-N3 -31~+31 0
F26 R-R -32~+32 3
F27 R-B -32~+32 -2
F28 B-R -32~+32 -8
F29 B-B -32~+32 6
F30 GAMM
A
0~3 1
F31 BS-D 0~3 0
F32 BS-C 0~3 0
F33 SL-TV 0~7 2
F34 SL-AV 0~7 2
F35 SL-YUV 0~7 0
F36 AFC2 0/1 0
F37 VD-TV 0~7 5
F38 VD-AV 0~7 7
F39 VD-YUV 0~7 1
F40 AS-TV 0/1 1
F41 AS-AV 0/1 1
F42 AS-YUV 0/1 0
F43 FBP-TV 0/1 0
F44 FBP-AV 0/1 0
F45 FBP-YUV 0/1 0
F46 C.Clip Level 0/1 0
F47 CP 0/1 1
F48 CC LEVEL 0~31 0
F49 OSD POS-H 0~31 0
F50 OSD POS-V50 1~55 38
F51 OSD POS-V60 1~50 23
F52 OFFSET-ADJ-COLO
R
-32~+32 10
F53 OFFSET-ADJ-TINT -32~+32 2
F54
WAIT㩺 MD㩺 TIMER
0/1 1
F55 R-CUT-YU
V
-63~+63 0
(SLOW MODE)
R-CUT (OFFSET)
COLOR
TINT
OSD POS
OSD POS
CC LEVEL
OSD POS
C.CLIP LEVEL
CP
FBP VTH
FBP VTH
AUTO-SLICE
FBP VTH
AUTO-SLICE
AUTO-SLICE
VSYNC-DET
VSYNC-DET
AFC2-G
VSYNC-DET
S-SLICE DOWN
S-SLICE DOWN
BS-CHARGE
S-SLICE DOWN
GAMMA
BS-DISCHARGE
B-DRI(OFFSET)
B-DRI(OFFSET)
R-DRI(OFFSET)
R-DRI(OFFSET)
COLOR(OFFSET)
COLOR(OFFSET)
TINT(OFFSET)
COLOR(OFFSET)
Y-DELAY
Y-DELAY
Y-DELAY
Y-DELAY
Y-DELAY
Y-DELAY
VIF-GAIN
Y-DELAY
CONTRAST(OFFSET)
F13 FAO-VOL A-ATT
VIDEO-TONE
EXTRGB-CLIP
VIDEO-TONE (OVER)
VIDEO-TONE (OVER)
VIDEO-TONE (OVER)
VIDEO-TONE (OVER)
VIDEO-TONE (PRE)
VIDEO-TONE (PRE)
VIDEO-TONE (PRE)
VIDEO-TONE (PRE)
Function
ABCL-G
