21V-FR95S
LX-BZ3049GEF7 Screw
LHLDW1047PEZZ Wire Holder
R1063 VRS-CY1JF103J 10k, 1/16W M-Ox.
R1064 VRS-CY1JF103J 10k, 1/16W M-Ox.
R1065 VRS-CY1JF103J 10k, 1/16W M-Ox.
R1066 VRS-CY1JF561J 560, 1/16W M-Ox.
R1072 VRS-CY1JF221J 220, 1/16W M-Ox.
R1073 VRD-RA2BE101J 100, 1/8W Carbon
R1074 VRS-CY1JF103J 10k, 1/16W M-Ox.
R1076 VRD-RA2BE102J 1k, 1/8W Carbon
R1081 VRS-CY1JF103J 10k, 1/16W M-Ox.
R1096 VRS-CY1JF103J 10k, 1/16W M-Ox.
R1097 VRS-CY1JF472J 4.7k, 1/16W M-Ox.
R1098 VRS-CY1JF104J 100k, 1/16W M-Ox.
R1801 VRD-RA2BE222J 2.2k, 1/8W Carbon
R1802 VRS-CY1JF124J 120k, 1/16W M-Ox.
R1850 VRS-CY1JF472J 4.7k, 1/16W M-Ox.
R1851 VRS-CY1JF221J 220, 1/16W M-Ox.
R1852 VRS-CY1JF221J 220, 1/16W M-Ox.
R1853 VRS-CY1JF221J 220, 1/16W M-Ox.
R1854 VRS-CY1JF103J 10k, 1/16W M-Ox.
R1855 VRD-RA2BE122J 1.2k, 1/8W Carbon
R1894 VRD-RA2BE103J 10k, 1/8W Carbon
R1895 VRS-CY1JF473J 47k, 1/16W Carbon
R1896 VRS-CY1JF473J 47k, 1/16W Carbon
S1001 QSW-K0003AJZZ Switch, CH-Up
S1002 QSW-K0003AJZZ Switch, CH-Down
S1003 QSW-K0003AJZZ Switch, VOL-Up
S1004 QSW-K0003AJZZ Switch, VOL-Down
S1005 QSW-K0003AJZZ Switch, MENU
S701 QSW-P0612CEZZ Switch, Power
! F701 QFS-B0102PFZZ Fuse, T3.15A
! FH701 QFSHD1013CEZZ Fuse Holder
! FH702 QFSHD1014CEZZ Fuse Holder
J402 QJAKE0210CE04 Jack, Video IN
J403 QJAKE0210CE09 Jack, L-Audio IN
J404 QJAKE0210CE02 Jack, R-Audio IN
J405 QTANJ0644CEZZ Rear AV IN/OUT
P302 QPLGN0441CEZZ Plug, 4-pin (S)
P601 QPLGN0660CEZZ Plug, 6-pin (F)
P602 QPLGN0441CEZZ Plug, 4-pin (H)
P603 QPLGN0341CEZZ
Plug, 3-pin (TP651~3)
P701 QPLGN0260CEZZ Plug, 2-pin (M)
P702 QPLGN0269GEZZ Plug, 2-pin
P1001 QPLGNA110WJZZ Plug, 5-pin (K)
P1002 QPLGNA110WJZZ Plug, 5-pin (BC)
RDA301 PRDARA121WJFW S-Out Heatsink
RDA501 PRDARA120WJFW V-Out Heatsink
RDA601 PRDARA181WJFW IC601 Heatsink
RDA602 PRDAR0337PEFW Horizontal Heatsink
RDA701 PRDARA119WJFW Power Heatsink
RMC1001 RRMCUA022WJZZ R/C Receiver
RY701 RRLYJ0089CEZZ Relay
LHLDP1066PE00 LED Holder
LX-BZ3100CEF7 Screw
SWITCHES
Part No. DescriptionRef. No.
MISCELLANEOUS PARTS
PWB-A: DUNTKD373WEA0 MAIN UNIT
Ref. No. Part No. Description
(Continued)
44
