Q853 RH-TX0110BMZZ TX0110BM IC3001 VHICXA2194Q-1S CXA2194Q
Q854 RH-TX0110BMZZ TX0110BM
Q855 RH-TX0110BMZZ TX0110BM
Q894 VS2SA1015Y/1E 2SA1015Y Q3001 VS2SD601AR/-1 2SD601AR
Q3002 VS2SD601AR/-1 2SD601AR
Q3004 VS2SD601AR/-1 2SD601AR
D859 VHD1SS119//-1 D1SS119 Q3005 VS2SD601AR/-1 2SD601AR
D898 VHD1SS119//-1 D1SS119 Q3006 VS2SD601AR/-1 2SD601AR
Q3007 VS2SD601AR/-1 2SD601AR
L851 VP-MK820K0000
Peaking 82
µ
H
C3001 VCE9GA1HW475M 4.7, 50V EL.
C3002 VCKYCY1HB562K 5600p, 50V Ceramic
C851 VCKYPA1HB271
K
220p, 50V Ceramic C3003 VCQYTA1HM123K 0.012, 50V Mylar
C852 VCKYPA1HB271
K
220p, 50V Ceramic C3004 VCEA0A1HW105M 1, 50V EL.
C853 VCKYPA1HB271
K
220p, 50V Ceramic C3005 VCEA0A1HW475M 4.7, 50V EL.
C880 RC-KZ0153CEZZ 0.001, 3.15kV Ceramic C3006 VCEA0A1CW106M 10, 16V EL.
C893 VCEA0A1CW336M 33, 16V EL. C3007 VCEA0A1HW475M 4.7, 50V EL.
C3008 VCKYCY1HF103Z 0.01, 50V Ceramic
C3009 VCEA0A1CW227M 220, 16V EL.
C3010 VCE9GA1HW475M 4.7, 50V EL.
R849 VRD-RA2BE331J 330, 1/8W Carbon C3011 VCEA0A1HW475M 4.7, 50V EL.
R850 VRD-RA2BE470J 47, 1/8W Carbon C3012 VCE9GA1HW475M 4.7, 50V EL.
R851 VRD-RA2BE470J 47, 1/8W Carbon C3013 VCKYCY1HB272K 2700p, 50V Ceramic
R852 VRD-RA2BE470J 47, 1/8W Carbon C3014 VCQYTA1HM473K 0.047, 50V Mylar
R854 VRD-RA2BE391J 390, 1/8W Carbon C3015 VCEACA1HC335K 3.3, 50V EL.
R855 VRD-RA2BE391J 390, 1/8W Carbon C3016 VCE9GA1HW475M 4.7, 50V EL.
! R859 VRS-VV3DB153J 15k, 2W M-Ox. C3017 VCEACA1CC106K 10, 16V EL.
! R861 VRS-VV3DB153J 15k, 2W M-Ox. C3018 VCEA0A1HW105M 1, 50V EL.
! R863 VRS-VV3DB153J 15k, 2W M-Ox. C3019 VCEA0A1CW106M 10, 16V EL.
R864 VRD-RA2BE470J 47, 1/8W Carbon C3020 VCEA0A1CW106M 10, 16V EL.
R876 VRD-RA2BE121J 120, 1/8W Carbon C3021 VCEA0A1CW106M 10, 16V EL.
R877 VRD-RA2BE121J 120, 1/8W Carbon C3022 VCEA0A1CW106M 10,16V EL.
R878 VRD-RA2BE121J 120, 1/8W Carbon C3023 VCKYCY1HF103Z 0.01, 50V Ceramic
R880 VRD-RM2HD332J 3.3k, 1/2W Carbon C3024 VCKYCY1HF103Z 0.01, 50V Ceramic
R881 VRD-RM2HD332J 3.3k, 1/2W Carbon C3025 VCKYCY1HF473Z 0.047, 50V Ceramic
R882 VRD-RM2HD332J 3.3k, 1/2W Carbon C3026 VCKYCY1HF473Z 0.047, 50V Ceramic
R889 VRD-RA2BE821J 820, 1/8W Carbon C3030 VCQYTA1HM682K 6800p, 50V Mylar
R891 VRD-RA2BE561J 560, 1/8W Carbon C3031 VCKYCY1HF682Z 6800p, 50V Mylar
R892 VRD-RA2BE391J 390, 1/8W Carbon C3034 VCEA0A1HW224M 0.22, 50V EL.
R894 VRD-RA2BE152J 1.5k, 1/8W Carbon C3037 VCEA0A1HW335M 3.3, 50V EL.
R895 VRD-RA2BE561J 560, 1/8W Carbon C3038 VCEA0A1HW335M 3.3, 50V EL.
C3039 VCEA0A1HW224M 0.22, 50V EL.
C3042 VCKYCY1HB681K 680p, 50V Ceramic
P860 QPLGN0441CEZZ Plug, 4-pin (H) C3043 VCKYCY1HB681K 680p, 50V Ceramic
P880 QPLGNA110WJZZ Plug, 5-pin (K) C3044 VCEA0A1EW476M 47, 25V EL.
SC851 QSOCV0933CEZZ CRT Socket C3045 VCEA0A1HW335M 3.3, 50V EL.
C3046 VCEA0A1HW335M 3.3, 50V EL.
C3047 VCEA0A1HW335M 3.3, 50V EL.
C3048 VCEA0A1HW335M 3.3, 50V EL.
Ref. No.
TRANSISTORS
CAPACITORS
[EL. …Electrolytic]
Part No. Description
PWB-B: DUNTKA599WEI1 CRT UNIT PWB-C: DUNTKC574WEA3 MTS UNIT
TRANSISTORS
[M-Ox. …Metal Oxide]
CAPACITORS
COIL
RESISTORS
DIODES
[EL. …Electrolytic]
INTEGRATED CIRCUITS
DescriptionRef. No. Part No.
21V-FR95S
MISCELLANEOUS PARTS
