21V-FW100S
4 – 2
Memory Map Data
Caution:
to get into the service mode, one of the ways is press direct key for service items.
There is three stage of Service Mode data
First stage data from V01 ~ M06
to go into second stage of service mode data, press MENU key
Second stage data from F01 ~ F101
to go into third stage of service mode data, press MENU key
Third stage data from O01 ~ O34
Below is the contents of these data
First Stage
Data Function Range Default Data
V01 CONTRAST 0~127 127
V02 TINT 0~127 64
V03 COLOR 0~127 64
V04 BRIGHT 0~255 128
V05 VIDEO-TONE 0~63 41
V06 V-SHIFT 0~7 4
V07 H-PHASE 0~31 16
V08 RF-DELAY 0~127 127
V09 V-SIZE 0~63 32
V10 V-SHIFT(OFFSET) -7~+7 0
V11 H-PHASE(OFFSET) -15~+15 0
V12 V-SIZE(OFFSET) -31~+31 0
V13 VIF-VCO 0~63 32
V14 R-CUTOFF 0~255 127
V15 G-CUTOFF 0~255 127
V16 B-CUTOFF 0~255 127
V17 R-DRIVE 0~127 64
V18 B-DRIVE 0~127 64
V19 COLOR 0~127 64
V20 BASEBAND-TINT 0~127 64
V21 CC-POS 0~255 32
V22 CUT OFF 0~2 0
V23 A-ATT 0~127 127
V24 H-VCO 0~7 4
V25 S-TRAPFINEADJ 0~15 7
V26 VS-CORRECTION 0~63 36
V27 VS-CORRECTION -13~+13 0
V28 V-LINEARITY 0~63 35
V29 V-LINEARITY -13~+13 0
M01 ATT (MTS) 0~15 10
M02 VCO (MTS) 0~63 32
M03 FILTER (MTS) 0~63 28
M04 WIDEBAND (MTS) 0~63 27
M05 SPECTRAL (MTS) 0~63 32
M06 VOL (MTS) 0~63 63
Auto Adjustment Item
1. H-VCO
2. RF-AGC
3. PIF-VCO
V LINEARITY OFFSET
MTS-WIDEBAND
MTS-SPECTRAL
SUB-VOL
SUB-PICTURE
SUB-TINT
SUB-BRIGHT
SUB-COLOR
Service Mode
SUB-SHARP
V-SHIFT
H-SHIFT
RF-AGC
V-SIZE
PIF-VCO
R-CUTOFF
G-CUTOFF
V-SHIFT50
H-SHIFT50
V-SIZE50
SCREEN CUT OFF
SUB-VOL
B-CUTOFF
R-DRIVE
B-DRIVE
SUB-COLOR(YUV)
SUB-TINT(YUV)
CC-POS
H-VCO
MTS-ATT
MTS-VCO
MTS-FILTER
S-TRAP
VS-CORRECT
VS-CORRECT OFFSET
V LINEARITY
