21V-FW100S
4 – 3
Second Stage
Data Function Range Default Data
F01 V-TONE 0/1 0
F02 V-TONE 0/1 0
F03 V-TONE 0/1 0
F04 ABCL 0/1 0
F05 BS-OFF 0/1 0
F06 ABCL-G 0/1 0
F07 VIDEO-TONE(OFFSET) -16~+16 0
F08 VIDEO-TONE(OFFSET) -16~+16 0
F09 VIDEO-TONE(OFFSET) -31~+31 0
F10 VIDEO-TONE(OFFSET) -31~+31 0
F11 EXTRGB-CLIP 0/1 0
F12 CONTRAST(OFFSET) 0~63 30
F13 A-ATT 0~127 120
F14 VIF-GAIN 0~7 5
F15 Y-DELAY 0~7 5
F16 Y-DELAY 0~7 5
F17 Y-DELAY 0~7 5
F18 Y-DELAY 0~7 5
F19 Y-DELAY 0~7 5
F20 Y-DELAY 0~7 5
F21 Y-DELAY 0~7 0
F22 TINT(OFFSET) -32~+32 +6
F23 COLOR(OFFSET) -32~+32 0
F24 COLOR(OFFSET) -31~+31 +24
F25 COLOR(OFFSET) -31~+31 0
F26 R-DRI(OFFSET) -32~+32 +8
F27 R-DRI(OFFSET) -32~+32 +3
F28 R-DRI(OFFSET) -32~+32 -2
F29 B-DRI(OFFSET) -32~+32 -18
F30 B-DRI(OFFSET) -32~+32 -8
F31 B-DRI(OFFSET) -32~+32 +6
F32 V-FREE 0/1 1
F33 GAMMA 0~3 1
F34 H-FREE 0/1 0
F35 V.WINDOW 0/1 0
F36 V.WINDOW 0/1 1
F37 YSW-LPF 0/1 0
F38 BS-DISCHARGE 0~3 0
F39 BS-CHARGE 0~3 0
F40 S-SLICE DOWN 0~7 2
F41 S-SLICE DOWN 0~7 2
F42 S-SLICE DOWN 0~7 0
F43 AFC2-G 0/1 0
F44 VSYNC-DET 0~3 3
F45 VSYNC-DET 0~3 2
F46 VSYNC-DET 0~3 0
F47 AUTO-SLICE 0/1 1
F48 AUTO-SLICE 0/1 1
F49 AUTO-SLICE 0/1 0
F50 FBP VTH 0/1 0
F51 FBP VTH 0/1 0
F52 FBP VTH 0/1 0
F53 C.CLIP LEVEL 0/1 0
F54 PSW 0/1 0
F55 VOL 0~63 58
F56 CHARGE PUMP 0/1 1
F57 CC LEVEL 0~31 0
F58 OSD POS 0~31 0
F59 OSD POS 1~55 38
F60 OSD POS 1~50 23
F61 COLOR -32~+32 +10
F62 TINT -32~+32 +2
OSD POS-V50
OSD POS-V60
Y-DELAY(AV-N3)
Y-DELAY(YUV)
COL-N3
SHP-P
SHP-N3
Y-DELAY(AV-P)
Service Mode
SHPG
SHPG-P
SHPG-N3
ABCL
BS
ABCL-G
SHP-AV
RGB-CLIP
E-SAVE
FAO-VOL
SHP-YUV
PIF-G
Y-DELAY(TV)
Y-DELAY(AV-P)
Y-DELAY(AV)
Y-DELAY(TV-N3)
TINT-AV
COL-AV
R-DRI(R2)
R-DRI( R)
COL-P
R-DRI(B)
B-DRI(R2)
B-DRI( R)
B-DRI(B)
V-FREE
GAMMA
H-FREE
1W(TV)
1W(AV)
YLPF
BS-D
BS-C
SL(TV)
SL(AV)
AFC2
VD(TV)
VD(AV)
SL(YUV)
VD(YUV)
AS(TV)
AS(AV)
AS(YUV)
FBP(TV)
FBP(AV)
C.CLIP LEVEL
PSW
FBP(YUV)
FAO-VOL
CP
CC LEVEL
OSD POS-H
OFFSET-ADJ-COL
OFFSET-ADJ-TINT
