Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
33
32F540
R2013 VRS-CY1JF682JY X 6.8k 1/16W Metal Oxide AA
R2021 VRS-CY1JF334JY X 330k 1/16W Metal Oxide AA
R2024 VRS-CY1JF472JY X 4.7k 1/16W Metal Oxide AA
R2025 VRS-CY1JF472JY X 4.7k 1/16W Metal Oxide AA
R2026 VRS-CY1JF472JY X 4.7k 1/16W Metal Oxide AA
R2027 VRS-CY1JF102JY X 1k 1/16W Metal Oxide AA
R2028 VRD-RA2BE102JY X 1k 1/8W Carbon AA
R2031 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R2033 VRS-CY1JF334JY X 330k 1/16W Metal Oxide AA
R2040 VRS-CY1JF102JY X 1k 1/16W Metal Oxide AA
R2041 VRS-CY1JF333JY X 33k 1/16W Metal Oxide AA
R2042 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R2043 VRS-CY1JF333JY X 33k 1/16W Metal Oxide AA
R2044 VRS-CY1JF153JY X 15k 1/16W Metal Oxide AA
R2045 VRS-CY1JF473JY X 47k 1/16W Metal Oxide AA
R2046 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R2047 VRS-CY1JF221JY X 220 1/16W Metal Oxide AA
R2048 VRS-CY1JF562JY X 5.6k 1/16W Metal Oxide AA
R2051 VRS-CY1JF102JY X 1k 1/16W Metal Oxide AA
R2054 VRS-CY1JF102JY X 1k 1/16W Metal Oxide AA
R2060 VRS-CY1JF221JY X 220 1/16W Metal Oxide AA
R2061 VRS-CY1JF562JY X 5.6k 1/16W Metal Oxide AA
R2062 VRS-CY1JF223JY X 22k 1/16W Metal Oxide AA
R2063 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R2064 VRS-CY1JF332JY X 3.3k 1/16W Metal Oxide AA
R2073 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
R2084 VRS-CY1JF103JY X 10k 1/16W Metal Oxide AA
R2086 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R2088 VRS-CY1JF224JY X 220k 1/16W Metal Oxide AA
R2089 VRS-CY1JF273JY X 27k 1/16W Metal Oxide AA
R2090 VRS-CY1JF682JY X 6.8k 1/16W Metal Oxide AA
R2092 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R2093 VRS-CY1JF224JY X 220k 1/16W Metal Oxide AA
R2094 VRS-CY1JF473JY X 47k 1/16W Metal Oxide AA
R2095 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R2096 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R2101 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R2102 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R2201 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R2202 VRS-CY1JF103JY X 10k 1/16W Metal Oxide AA
R2203 VRS-CY1JF473JY X 47k 1/16W Metal Oxide AA
R2211 VRS-CY1JF222JY X 2.2k 1/16W Metal Oxide AA
R2212 VRS-CY1JF682JY X 6.8k 1/16W Metal Oxide AA
R2213 VRS-CY1JF333JY X 33k 1/16W Metal Oxide AA
R2401 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2402 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2403 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2404 VRD-RA2BE101JY X 100 1/8W Carbon AA
R2501 VRS-CY1JF183JY X 18k 1/16W Metal Oxide AA
R2502 VRS-CY1JF183JY X 18k 1/16W Metal Oxide AA
R2503 VRS-CY1JF103JY X 10k 1/16W Metal Oxide AA
R2504 VRS-CY1JF103JY X 10k 1/16W Metal Oxide AA
R2509 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
R3001 VRS-CY1JF221JY X 220 1/16W Metal Oxide AA
R3002 VRS-CY1JF221JY X 220 1/16W Metal Oxide AA
R3003 VRS-CY1JF105JY X 1M 1/16W Metal Oxide AA
R3004 VRS-CY1JF104JY X 100k 1/16W Metal Oxide AA
R3005 VRS-CY1JF623JY X 62k 1/16W Metal Oxide AA
R3007 VRS-CY1JF332JY X 3.3k 1/16W Metal Oxide AA
R3008 VRS-CY1JF302JY X 3k 1/16W Metal Oxide AA
R3010 VRS-CY1JF392JY X 3.9k 1/16W Metal Oxide AA
R3017 VRS-CY1JF102JY X 1k 1/16W Metal Oxide AA
R3018 VRS-CY1JF102JY X 1k 1/16W Metal Oxide AA
R3019 VRS-CY1JF101JY X 100 1/16W Metal Oxide AA
R3024 VRD-RA2BE102JY X 1k 1/8W Carbon AA
BALUNES
FB601 RBLN-0047CEZZY X Balun AB
FB706 RBLN-0037CEZZY X Balun AB
FB2001RBLN-0037CEZZY X Balun AB
MISCELLANEOUS PARTS
å ACC701 QACCDA012WJPZ X AC Cord AE
FH701 QFSHD1013CEZZ+ X Fuse Holder AB
FH702 QFSHD1014CEZZ+ X Fuse Holder AB
å F701 QFS-B4023CEZZ X Fuse, 4A/125V AB
J921 QSOCD0456CEZZ X Socket, S-Video AC
J1401 QTANJ1101SEZZ X In Out Jack AF
P361 QPLGN0461CEZZA X Plug, 4Pin(S) AB
P401 QPLGN0861CEZZA X Plug, 8Pin(CJ) AB
P601 QPLGN0161FJZZ X Plug, 6Pin(K) AB
P621 QPLGN0761CEZZA X Plug, 7Pin(N) AB
P651 QPLGN0361CEZZA X Plug, 3Pin(TP651-3) AB
P702 QPLGN0269GEZZ X Plug, 2Pin(P) AB
P703 QPLGN0260CEZZ X Plug, 2Pin(M) AB
P1301 QPLGN0661CEZZA X Plug, 6Pin(EJ) AB
P2003 QPLGN0561CEZZA X Plug, 5Pin(KA) AB
P2401 QPLGN0661CEZZA X Plug, 6Pin AB
RDA361 PRDAR0258PEFW X Heat Sink for IC361 AC
RDA501 PRDARA039WJFW X Heat Sink for IC501 AD
RDA601 PRDARA041WJFW X Heat Sink for Q602 AD
RDA671 PRDARA057WJFW X Heat Sink for Q673 AC
RDA701 PRDAR0279PEFW X Heat Sink for Q701 AB
RDA750 PRDAR5072CEFW X Heat Sink for IC751 AB
RDA1403 PRDAR5072CEFW X Heat Sink for IC1403 AB
å RY701 RRLYJ0081CEZZ X Relay AD
RY702 RRLYJ0088CEZZ X Relay AC
CF2040 RCRM-0003CEZZ+ X Ceramic Vibrator AC
TP701 QLUGP0102PEZZ X Lug AA
DUNTKA527WEW7
PWB-B CRT UNIT
INTEGRATED CIRCUIT
å IC850 VHiTDA6103Q-1 X TDA6103Q/N3 AG
TRANSISTORS
Q850 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q851 VS2SC3198-G-1+ X 2SC3198-G AB
Q1504 VS2SC3198-G-1+ X 2SC3198-G AB
Q1505 VS2SA1266-Y-1+ X 2SA1266-Y AB
Q1506 VS2SA1964E/-1 X 2SA1964E AC
Q1507 VS2SC5248E/-1 X 2SC5248E AC
DIODES
D850 RH-DX0220CEZZY X DX0220CE AB
D851 RH-DX0220CEZZY X DX0220CE AB
D852 RH-DX0220CEZZY X DX0220CE AB
D853 RH-EX0647GEZZY X Zener Diode, 15V AB
D854 VHD1SS119//-1Y X 1SS119 AA
D855 VHD1SS119//-1Y X 1SS119 AA
D862 VHD1SS119//-1Y X 1SS119 AA
D1502 VHD1SS119//-1Y X 1SS119 AA
D1503 VHD1SS119//-1Y X 1SS119 AA
D1506 RH-DX0487CEZZY X DX0487CE AB
D1507 RH-DX0487CEZZY X DX0487CE AB
D1510 VHD1SS119//-1Y X 1SS119 AA
CAPACITORS
C850 VCFYSB2EB224K X 0.22 250V AB
C851 RC-KZ018JCEZZ X 0.01 AC250V Ceramic AB
C852 VCEA0A1CW107M+X 100 16V Electrolytic AB
C853 VCFYFA1HA224J+ X 0.22 50V Mylar AB
C854 VCEA0A1CW227M+X 220 16V Electrolytic AB
C855 VCEA0A2EW106M+X 10 250V Electrolytic AB
C856 VCEA0A1HW226M+X 22 50V Electrolytic AB
C1501 VCEA0A1CW476M+X 47 16V Electrolytic AB
C1506 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1508 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C1509 VCKYPA1HB472K+ X 4700p 50V Ceramic AB
C1510 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1511 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1515 VCEA0A1HW476M+X 47 50V Electrolytic AB
C1516 VCEA0A1HW476M+X 47 50V Electrolytic AB
C1517 VCEA0A2AW106M+X 10 100V Electrolytic AB
C1518 VCCSPA2HL560K+ X 56p 500V Ceramic AB
C1519 VCEA0A2CW106M+X 10 160V Electrolytic AB
