Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
34
32F540
RESISTORS
å R850 VRS-SV2HC152J X 1.5k 1/2W Metal Oxide AB
å R851 VRS-SV2HC152J X 1.5k 1/2W Metal Oxide AB
å R852 VRS-SV2HC152J X 1.5k 1/2W Metal Oxide AB
å R853 VRS-SV2HC272J X 2.7k 1/2W Metal Oxide AB
å R854 VRS-SV2HC272J X 2.7k 1/2W Metal Oxide AB
å R855 VRS-SV2HC272J X 2.7k 1/2W Metal Oxide AB
R856 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R857 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R858 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R861 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R862 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
R863 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
R864 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
å R867 VRS-SV2HC392J X 3.9k 1/2W Metal Oxide AB
å R868 VRS-SV2HC682J X 6.8k 1/2W Metal Oxide AB
R869 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R870 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R871 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
R872 VRD-RA2EE680JY X 68 1/4W Carbon AA
R873 VRD-RM2HD224JY X 220k 1/2W Carbon AA
R874 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R875 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R876 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R877 VRD-RA2BE103JY X 10k 1/8W Carbon AA
å R878 VRS-SV2HC120J X 12 1/2W Metal Oxide AB
R1511 VRD-RA2BE101JY X 100 1/8W Carbon AA
å R1513 VRS-VV3DB561J X 560 2W Metal Oxide AB
R1514 VRD-RA2BE100JY X 10 1/8W Carbon AA
R1515 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1516 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1517 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1518 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1519 VRD-RA2BE123JY X 12k 1/8W Carbon AA
R1520 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1521 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1525 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1526 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1527 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
R1528 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
å R1529 VRS-VV3DB221J X 220 2W Metal Oxide AB
R1530 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
BALUN
FB1501RBLN-0020CEZZ+ X Balun AB
MISCELLANEOUS PARTS
P854 QPLGN0741CEZZ X Plug, 7Pin(N) AB
P860 QPLGN0841CEZZ X Plug, 8Pin(CJ) AB
å P861 QPLGN0241CEZZ X Plug AB
RDA850 PRDAR0248PEFW X Heat Sink for IC850 AB
RDA1506 PRDAR5072CEFW X Heat Sink for Q1506 AB
RDA1507 PRDAR5072CEFW X Heat Sink for Q1507 AB
SC850 QSOCV1011CEZZ X Socket, 12Pin AC
DUNTKB572WEV0
PWB-D 2 LINE Y/C UNIT
INTEGRATED CIRCUIT
IC1401 VHiTC90A45F-1Y X TC90A45F AH
TRANSISTORS
Q1401 VS2SD601AR/-1Y X 2SD601AR AB
Q1402 VS2SD601AR/-1Y X 2SD601AR AB
Q1404 VS2SB709AR/-1Y X 2SB709AR AB
COILS
L1401 VP-XF100K0000Y X Peaking, 10µHAB
L1402 VP-XF100K0000Y X Peaking, 10µHAB
L1403 VP-XF100K0000Y X Peaking, 10µHAB
L1404 VP-XF220K0000Y X Peaking, 22µHAB
L1405 VP-XF220K0000Y X Peaking, 22µHAB
L1408 VP-XF100K0000Y X Peaking, 10µHAB
CAPACITORS
C1401 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1402 VCEA0A1AW227M+X 220 10V Electrolytic AB
C1403 VCCCCY1HH330JY X 33p 50V Ceramic AA
C1404 VCCCCY1HH181JY X 180p 50V Ceramic AB
C1405 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1406 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1407 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1408 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1409 VCEA0A1CW476M+X 47 16V Electrolytic AB
C1410 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1411 VCKYCY1HB103KYX 0.01 50V Ceramic AA
C1412 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1413 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1414 VCE9GA1HW105M+X 1 50V Electrolytic AB
C1415 VCCCCY1HH120JY X 12p 50V Ceramic AA
C1416 VCCCCY1HH3R0CYX 3p 50V Ceramic AA
C1417 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1418 VCCCCY1HH120JY X 12p 50V Ceramic AA
C1419 VCCCCY1HH3R0CYX 3p 50V Ceramic AA
C1420 VCCCCY1HH270JY X 27p 50V Ceramic AA
C1423 VCFYFA1HA474J+ X 0.47 50V Mylar AB
C1424 VCEA0A1CW107M+X 100 16V Electrolytic AB
C1425 VCCCCY1HH820JY X 82p 50V Ceramic AA
C1429 VCEA0A1CW107M+X 100 16V Electrolytic AB
C1430 VCKYCY1CB104KY X 0.1 16V Ceramic AA
C1431 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1432 VCKYCY1HB103KY X 0.01 50V Ceramic AA
RESISTORS
R1401 VRS-CY1JF821JY X 820 1/16W Metal Oxide AA
R1402 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
R1403 VRS-CY1JF361JY X 360 1/16W Metal Oxide AA
R1415 VRS-CY1JF391JY X 390 1/16W Metal Oxide AA
R1416 VRS-CY1JF102JY X 1k 1/16W Metal Oxide AA
R1417 VRS-CY1JF152JY X 1.5k 1/16W Metal Oxide AA
R1421 VRS-CY1JF152FY X 1.5k 1/16W Metal Oxide AA
R1423 VRS-CY1JF102FY X 1k 1/16W Metal Oxide AA
R1427 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
R1428 VRD-RA2BE332JY X 3.3k 1/8W Carbon AA
R1429 VRS-CY1JF000JY X 0 1/16W Metal Oxide AA
R1430 VRS-CY1JF151JY X 150 1/16W Metal Oxide AA
MISCELLANEOUS PART
P1401 QPLGZ0810CEZZ X Plug, 8Pin(CJ) AB
DUNTKB207WEA5
PWB-F CONTROL UNIT
CAPACITOR
C4001 VCEA0A1HW476M+X 47 50V Electrolytic AB
RESISTORS
R4001 VRD-RA2BE470JY X 47 1/8W Carbon AA
R4006 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R4007 VRD-RA2BE822JY X 8.2k 1/8W Carbon AA
R4009 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R4011 VRD-RA2BE183JY X 18k 1/8W Carbon AA
R4020 VRD-RA2BE750JY X 75 1/8W Carbon AA
SWITCHES
S4001 QSW-KA003WJZZ+ X Switch, POWER AB
S4002 QSW-KA003WJZZ+ X Switch, MENU AB
S4003 QSW-KA003WJZZ+ X Switch, VOL.-DOWN AB
S4004 QSW-KA003WJZZ+ X Switch, VOL.-UP AB
S4005 QSW-KA003WJZZ+ X Switch, CH-DOWN AB
S4006 QSW-KA003WJZZ+ X Switch, CH-UP AB
MISCELLANEOUS PARTS
J4001 QJAKGA031WJZZ X Input-2 Jack AC
P4001 QPLGN0641CEZZ X Plug, 6Pin(EJ) AB
P4004 QPLGN0541CEZZ X Plug, 5Pin(KA) AB
RMC4001 RRMCU0222CEZZ X Remote Receiver AD
