Page #23 background imageLoading...
Page #23 background image
23
IR & KEY board
Main board
LCD panel
backlight cable
LVDS cable
IR & KEY cable
power cord Speakers
Speaker’s cable
TV schematic diagram
3. WIRING DIAGRAM
