Sharp 32R-S400 User Manual

46
Specifications
• Design and specifications are subject to change without notice.
MODEL 32R-S400 36R-S400
Receiving System NTSC
Reception Channels
AIR VHF 2-13 ch
UHF 14-69 ch
CATV 1-125 ch
Channel Tuning 181-channel Reception PLL tuning system
Antenna Input Impedance VHF/UHF 75 ohm Unbalance
Screen Size 32˝ Diagonally Measured 36˝ Diagonally Measured
Terminals Audio/Video input x 2 (Front x 1, Rear x 1)
S-Video input x 1 (rear)
Sound Output 3.0 W (RMS) x 2
Power Source AC 120 V, 60 Hz
Power Consumption 140 W 165 W
Dimensions 30
21
/
64
˝ x 26
7
/
8
˝ x 21
57
/
64
˝34
47
/
64
˝ x 29
55
/
64
˝ x 24
25
/
32
˝
[(W) x (H) x (D)]mm [784.0 x 682.0 x 555.0] [882.0 x 758.0 x 629.0]
Weight (approx.) 114.6 lbs. (52.0 kg) 154.0 lbs. (70.0 kg)
46-48[Bk] 32/36R-S400.p65e 16/4/01, 11:38 AM46

Sharp 32R-S400 Specifications

General

Brand	Sharp
Model	32R-S400
Category	CRT TV
Language	English
