Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
35
32R-S480
CR32S48
C811 VCKYCY1HB103K J 0.01 50V Ceramic AA
C812 VCKYCY1HB103K J 0.01 50V Ceramic AA
C813 VCEA0A1CW107M J 100 16V EL. AC
C814 VCKYCY1HB103K J 0.01 50V Ceramic AA
C815 VCKYCY1HB103K J 0.01 50V Ceramic AA
C816 VCEA0A1CW107M J 100 16V EL. AC
C817 VCKYCY1HB103K J 0.01 50V Ceramic AA
C930 VCEA0A1HW335M J 3.3 50V EL. AB
C931 VCQYTA1HM183J J 0.018 50V Mylar AB
C932 VCQYTA1HM183J J 0.018 50V Mylar AB
C933 VCEA0A1HW335M J 3.3 50V EL. AB
C934 VCEA0A1CW476M J 47 16V EL. AB
C935 VCEA0A1HW335M J 3.3 50V EL. AB
C936 VCEA0A1HW335M J 3.3 50V EL. AB
C945 VCKYCY1HB102K J 1000p 50V Ceramic AA
C946 VCEA0A1HW225M J 2.2 50V EL. AB
C948 VCEA0A1HW225M J 2.2 50V EL. AB
C956 VCEA0A1CW337M J 330 16V EL. AC
C960 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C961 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C962 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C2001 VCCCCY1HH331J J 330p 50V Ceramic AA
C2003 VCEA0A1HW106M J 10 50V EL. AB
C2004 VCEA0A1CW476M J 47 16V EL. AB
C2005 VCEA0A1CW106M J 10 16V EL. AB
C2040 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C2041 VCEA0A1HW105M J 1.0 50V EL. AB
C2042 VCCCCY1HH101J J 100p 50V Ceramic AA
C2043 VCKYCY1HB103K J 0.01 50V Ceramic AA
C2044 VCQYTA1HM104J J 0.1 50V Mylar AA
C2060 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C2061 VCCCCY1HH101J J 100p 50V Ceramic AA
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2063 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C2064 VCKYCY1CF104Z J 0.1 16V Ceramic AA
C2201 VCKYCY1HB681K J 680p 50V Ceramic AA
C2202 VCCCCY1HH390J J 39p 50V Ceramic AA
C2203 VCCCCY1HH101J J 100p 50V Ceramic AA
C2601 VCEA0A1HW476M J 47 50V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film··· Metal Film]
RJ11 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ12 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ13 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ14 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ17 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ18 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ19 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ21 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ22 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ25 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ26 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ28 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ29 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ31 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ32 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ33 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ34 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ35 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ37 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ38 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ39 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ40 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ41 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ43 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ44 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ46 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ52 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ53 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ54 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ55 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ56 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ57 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ58 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ60 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ61 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ62 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ63 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ64 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ65 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ66 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ67 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ68 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ69 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ70 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ71 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ72 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ73 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ74 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ76 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ78 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ79 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ80 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ81 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ82 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ83 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ84 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ86 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ87 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ88 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ90 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ94 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ95 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ97 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R57 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R201 VRS-CY1JF151J J 150 1/16W M-Ox. AA
R202 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R204 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R211 VRS-CY1JF331J J 330 1/16W M-Ox. AA
R212 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R215 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R217 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R219 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R220 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R225 VRD-RA2BE680J J 68 1/8W Carbon AA
R226 VRD-RA2BE101J J 100 1/8W Carbon AB
R227 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R228 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R229 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R233 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R234 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R235 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R236 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R307 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R361 VRS-CY1JF224J J 220k 1/16W M-Ox. AA
R362 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R363 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R364 VRS-CY1JF561J J 560 1/16W M-Ox. AA
R365 VRS-CY1JF561J J 560 1/16W M-Ox. AA
R367 VRN-RL3DBR56J+ X 0.56 2W M-Film AE
R368 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R369 VRD-RA2BE822J J 8.2k 1/8W Carbon AA
R370 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R371 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R372 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R415 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R430 VRD-RA2BE331J J 330 1/8W Carbon AA
R431 VRS-CY1JF331J J 330 1/16W M-Ox. AA
R432 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R440 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R453 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R454 VRD-RA2BE101J J 100 1/8W Carbon AB
R471 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
PWB-A: DUNTKA526WEB3(32R-S480)
PWB-A: DUNTKA526WEB8(CR32S48)
MAIN UNIT (Continued)
