Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
38
32R-S480
CR32S48
P2401 QPLGN0561CEZZ J Plug, 5-pin AB
SC3001 QSOCN0259FJ00 J Socket, 10-pin(EA) AE
RMC2601 RRMCU0222CEZZ J R/C Receiver AL
or
RRMCU0235CEZZ
RDA361 PRDAR0108GJFW X Heat Sink, for IC361 AG
RDA501 PRDAR0113GJFW X Heat Sink, for IC501 AH
RDA602 PRDAR0114GJFW X Heat Sink, for Q602 AH
RDA673 PRDAR1007MEFW J Heat Sink, for Q673 AH
RDA701 PRDAR0117GJFW X Heat Sink, for Q701 AL
RDA751 PRDAR0111GJFW X Heat Sink, for IC751 AF
TP51 QLUGP0102PEZZ R Lug, Test Point AA
MSPRK0034BMFW J Spring AC
LHLDW1002PEZZ R Holder AB
LX-BZ3049GEFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-HZ3007MEFD X Screw AF
PWB-B: DUNTKA527WEA2
CRT UNIT
INTEGRATED CIRCUIT
å IC850 VHiTDA6103Q-1 J TDA6103Q/N3 AL
TRANSISTORS
Q850 VS2SA1266-Y-1 J A1266-Y AA
Q851 VS2SC3198-G-1 J C3198-G AA
Q1504 VS2SC3198-G-1 J C3198-G AA
Q1505 VS2SA1266-Y-1 J A1266-Y AA
Q1506 VS2SA1964E/-1 J A1964E AF
Q1507 VS2SC5248E/-1 J C5248E AE
DIODES
D853 RH-EX0647GEZZ J Zener Diode, 15V AA
or
RH-EX0417GEZZ
D854 VHD1SS119//-1 J Diode AB
D855 VHD1SS119//-1 J Diode AB
D1502 VHD1SS119//-1 J Diode AB
D1503 VHD1SS119//-1 J Diode AB
D1506 RH-DX0487CEZZ J Diode AC
D1507 RH-DX0487CEZZ J Diode AC
D1510 VHD1SS119//-1 J Diode AB
CAPACITORS
[EL.··· Electrolytic]
C850 VCFYSB2EB823J J 0.082 250V Mylar AD
C851 RC-KZ018JCEZZ J 0.01 AC250V Ceramic AC
or
RC-KZ015JCEZZ
C852 VCEA0A1CW227M J 220 16V EL. AC
C853 VCFYFA1HA224J J 0.22 50V Mylar AB
C854 VCEA0A1CW227M J 220 16V EL. AC
C855 VCEA0A2EW106M J 10 250V EL. AD
C856 VCEA0A1CW106M J 10 16V EL. AB
C1501 VCEA0A1EW476M J 47 25V EL. AB
C1506 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1508 VCKYPA2HB472K J 4700p 500V Ceramic AB
C1509 VCKYPA1HB472K J 4700p 50V Ceramic AA
C1510 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1511 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C1515 VCEA0A1EW476M J 47 25V EL. AB
C1516 VCEA0A1EW476M J 47 25V EL. AB
C1517 VCEA0A2AW106M J 10 100V EL. AC
C1518 VCCSPA2HL560K J 56p 500V Ceramic AA
C1519 VCEA0A2CW106M J 10 160V EL. AD
RESISTORS
[M-Ox.··· Metal Oxide]
R850 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA
R851 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA
R852 VRS-SV2HC152J J 1.5k 1/2W M-Ox. AA
å R853 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
å R854 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
å R855 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
R856 VRD-RM2HD224J J 220k 1/2W Carbon AA
R857 VRD-RM2HD224J J 220k 1/2W Carbon AA
R858 VRD-RM2HD224J J 220k 1/2W Carbon AA
R862 VRC-MA2HG152K J 1.5k 1/2W Solid AA
R863 VRC-MA2HG152K J 1.5k 1/2W Solid AA
R864 VRC-MA2HG152K J 1.5k 1/2W Solid AA
R867 VRS-SV2HC392J J 3.9k 1/2W M-Ox. AA
R868 VRS-SV2HC222J J 2.2k 1/2W M-Ox. AA
R870 VRD-RA2BE223J J 22k 1/8W Carbon AA
R871 VRD-RA2BE223J J 22k 1/8W Carbon AA
R872 VRD-RA2EE680J J 68 1/4W Carbon AA
R873 VRD-RM2HD224J J 220k 1/2W Carbon AA
R874 VRD-RM2HD184J J 180k 1/2W Carbon AA
R875 VRD-RM2HD184J J 180k 1/2W Carbon AA
R876 VRD-RM2HD184J J 180k 1/2W Carbon AA
R877 VRD-RA2BE103J J 10k 1/8W Carbon AA
R878 VRS-SV2HC120J J 12 1/2W M-Ox. AA
R1511 VRD-RA2BE101J J 100 1/8W Carbon AB
R1513 VRS-VV3DB561J J 560 2W M-Ox. AA
R1514 VRD-RA2BE100J J 10 1/8W Carbon AA
R1515 VRD-RA2BE820J J 82 1/8W Carbon AA
R1516 VRD-RA2BE820J J 82 1/8W Carbon AA
R1517 VRD-RA2BE122J J 1.2k 1/8W Carbon AA
R1518 VRD-RA2BE683J J 68k 1/8W Carbon AA
R1519 VRD-RA2BE123J J 12k 1/8W Carbon AA
R1520 VRD-RA2BE683J J 68k 1/8W Carbon AA
R1521 VRD-RA2BE122J J 1.2k 1/8W Carbon AA
R1522 VRD-RA2EE471J J 470 1/4W Carbon AA
R1525 VRD-RA2EE560J J 56 1/4W Carbon AA
R1526 VRD-RA2EE560J J 56 1/4W Carbon AA
R1527 VRD-RM2HD1R5J J 1.5 1/2W Carbon AA
R1528 VRD-RM2HD1R5J J 1.5 1/2W Carbon AA
R1529 VRS-VV3DB221J J 220 2W M-Ox. AA
R1530 VRD-RA2BE122J J 1.2k 1/8W Carbon AA
MISCELLANEOUS PARTS
FB1501 RBLN-0020CEZZ J Ferrite Bead AB
P852 QPLGN0341CEZZ J Plug, 3-pin(PU) AA
P854 QPLGN0741CEZZ J Plug, 7-pin(YBN) AC
P860 QPLGN0841CEZZ J Plug, 8-pin(GBN) AB
SC850 QSOCV0937CEZZ J CRT Socket AL
RDA850 PRDAR0248PEFW R Heat Sink, for IC850 AF
RDA1506 PRDAR5072CEFW J Heat Sink, for Q1506 AC
RDA1507 PRDAR5072CEFW J Heat Sink, for Q1507 AC
LX-BZ3100CEFD J Screw AA
PWB-A: DUNTKA526WEB3(32R-S480)
PWB-A: DUNTKA526WEB8(CR32S48)
MAIN UNIT (Continued)
