Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
41
32R-S480
CR32S48
C1863 VCCCCY1HH101J J 100p 50V Ceramic AA
C1865 VCFYFA1HA154J J 0.15 50V Mylar AC
C1866 VCQYTA1HM103J J 0.01 50V Mylar AA
C1867 VCKYCY1CB104K J 0.1 16V Ceramic AB
C1868 VCFYFA1HA474J J 0.47 50V Mylar AC
C1869 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C1870 VCEA0A1HW106M J 10 50V EL. AB
C1871 VCEA0A1HW106M J 10 50V EL. AB
C1872 VCKYCY1HF103Z J 0.01 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ4 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ8 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ11 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ12 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ13 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ14 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R1721 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R1722 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1723 VRS-CY1JF822J J 8.2k 1/16W M-Ox. AA
R1724 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R1741 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R1742 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1743 VRS-CY1JF151J J 150 1/16W M-Ox. AA
R1744 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R1745 VRS-CY1JF474J J 470k 1/16W M-Ox. AA
R1746 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R1747 VRD-RA2BE822J J 8.2k 1/8W Carbon AA
R1761 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1762 VRS-CY1JF151J J 150 1/16W M-Ox. AA
R1763 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1764 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R1765 VRS-CY1JF474J J 470k 1/16W M-Ox. AA
R1766 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R1791 VRD-RA2BE151J J 150 1/8W Carbon AA
R1801 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R1821 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R1822 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R1823 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R1825 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R1828 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R1831 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R1832 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R1833 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R1834 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R1841 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R1842 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R1843 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R1861 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R1862 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1863 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R1864 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R1865 VRS-CY1JF474J J 470k 1/16W M-Ox. AA
R1866 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R1867 VRS-CY1JF202J J 2.0k 1/16W M-Ox. AA
R1868 VRS-CY1JF510J J 51 1/16W M-Ox. AA
R1871 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R1881 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R1882 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1883 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R1884 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R1885 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R1886 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R1887 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R1889 VRD-RA2BE101J J 100 1/8W Carbon AB
MISCELLANEOUS PARTS
P1701 QPLGZ0810CEZZ J Plug, 8-pin AD
P1702 QPLGZ0610CEZZ J Plug, 6-pin AB
P1703 QPLGZ0810CEZZ J Plug, 8-pin AD
SLD1801 PSLDM0012MEFW J Shield AD
PWB-S: DUNTKA070WEV3
MTS MODULE UNIT
INTEGRATED CIRCUIT
IC3001 VHiCXA2074Q-1 J CXA2074Q AY
CAPACITORS
[EL.··· Electrolytic]
C3001 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA
C3003 VCQYTA1HM123J J 0.012 50V Mylar AA
C3004 VCEA0A1HW105M J 1.0 50V EL. AB
C3005 VCEA9A1HW475M J 4.7 50V EL. AB
C3006 VCEA0A1HW106M J 10 50V EL. AB
C3007 VCEA0A1HW475M J 4.7 50V EL. AB
C3008 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C3009 VCEA0A1CW227M J 220 16V EL. AC
C3010 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3011 VCEA0A1HW475M J 4.7 50V EL. AB
C3012 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA
C3014 VCQYTA1HM473J J 0.047 50V Mylar AA
C3015 VCEACA1HC335K X 3.3 50V EL. AF
C3016 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
C3017 VCEACA1CC106K J 10 16V EL. AC
C3018 VCEA0A1HW105M J 1.0 50V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ4 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
R3001 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R3002 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R3003 VRS-CY1JF105J J 1.0M 1/16W M-Ox. AA
R3004 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R3005 VRS-CY1JF623J J 62k 1/16W M-Ox. AA
R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R3008 VRS-CY1JF302J J 3.0k 1/16W M-Ox. AA
R3010 VRS-CY1JF392J J 3.9k 1/16W M-Ox. AA
R3011 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R3012 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R3373 VRS-CY1JF000J J 0 1/16W M-Ox. AA
MISCELLANEOUS PARTS
P3001 QPLGN0242FJ00 J Plug, 10-pin(EA) AE
PWB-R: DUNTKA533WEA0
P-IN-P UNIT (Continued)
