7
32U-S50, 32U-S60
36U-S60
SERVICE
NUMBER
DATA
ADJUSTMENT ITEM
INITIAL VALUE
RANGE
V01 PICTURE 03 0-15(00h-0Fh)
V02 TINT 3E 0-127(00h-7Fh)
V03 COLOR 2D 0-127(00h-7Fh)
V04 SUB-COLOR 10 0-31(00h-1Fh) Must be set to "10"
V05 BRIGHT 4D 0-127(00h-7Fh)
V06 R CUT-OFF 40 64-255(40h-FFh)
V07 G CUT-OFF 40 64-255(40h-FFh)
V08 B CUT-OFF 40 64-255(40h-FFh)
V09 G DRIVE 40 0-127(00h-7Fh)
V10 B DRIVE 40 0-127(00h-7Fh)
V11 SHARP 14 0-63(00h-3Fh) Must be set to "1E"
V12 N PHASE 01 0-3(00h-03h) Must be set to "01"
V13 DC RESTORATION 00 0-3(00h-03h) Must be set to "00"
V14 BLACK STRETCH 03 0-3(00h-03h) Must be set to "03"
V15 ABL START POINT 03 0-3(00h-03h) Must be set to "03"
V16 ABL GAIN 02 0-3(00h-03h) Must be set to "02"
V17 γ POINT 00 0-3(00h-03h) Must be set to "00"
V18 Y-MUTE/V-STOP 00 0-2 "00"=Normal, "01"=No-Y, "02"=No-Y & No-Vertical
V19 ENERGY SAVE 28 0-63(00h-3Fh) Must be set to "28"
V20 RTONE-G F6 0-255(00h-FFh) Must be set to "F6"
V21 RTONE-B F6 0-255(00h-FFh) Must be set to "F6"
V22 BTONE-G 00 0-255(00h-FFh) Must be set to "00"
V23 BTONE-B 0A 0-255(00h-FFh) Must be set to "0A"
V24 LOW-G F7 0-255(00h-FFh) Must be set to "F7"
V25 LOW-B E8 0-255(00h-FFh) Must be set to "E8"
V26 ML-G 00 0-255(00h-FFh) Must be set to "00"
V27 ML-B F9 0-255(00h-FFh) Must be set to "F9"
V28 HIGH-G 03 0-255(00h-FFh) Must be set to "03"
V29 HIGH-B 06 0-255(00h-FFh) Must be set to "06"
V30 WPS 01 0-1 Must be set to "01"
V31 RGB CONTRAST 20 0-63(00h-3Fh) Must be set to "2A"
V32 Y-DL 02 0-7(00h-07h) Must be set to "02"
V33 Y-DL-INPUT 01 0-7(00h-07h) Must be set to "01"
V34 VSM GAIN 07 0-7(00h-07h) Must be set to "07"
V35 N COMB 01 0-1 Must be set to "01"
V36 BPF/TOF-INPUT 00 0-1 Must be set to "00"
V37 CORING 00 0-1 Must be set to "00"
V38 VSM PHASE 00 0-1 Must be set to "00"
V39 COLOR γ 00 0-1 Must be set to "00"
V40 SHARP-INPUT 14 0-63(00h-3Fh) Must be set to "1E"
V41 TINT-INPUT 3E 0-127(00h-7Fh)
V53 C-TRAP 00 0-1 Must be set to "00"
R01 RF-AGC 24 0-63(00h-3Fh)
R02 PIF VCO coil –
R03 RF-AGC REF 5C 0-255(00h-FFh) Must be set to "5C"
D01 V POSITION 00 0-7(00h-07h)
D02 H POSITION 10 0-31(00h-1Fh)
D03 V SIZE 12 0-63(00h-3Fh)
D04 H SIZE 1F 0-63(00h-3Fh)
D05 V-LINEARITY 07 0-15(00h-0Fh)
D06 V-S CORRECTION 08 0-15(00h-0Fh) Must be set to "08"
D07 EW PARABOLA 21 0-63(00h-3Fh)
D08 EW TRAPEZIUM 0E 0-31(00h-1Fh)
D09 EW CORNER 0C 0-15(00h-0Fh)
D10 AFC GAIN 02 0-3(00h-03h) Must be set to "02"
D11 V EHT 07 0-7(00h-07h) Must be set to "07"
D12 H EHT 03 0-7(00h-07h) Must be set to "03"
EX1 FAO VOLUME 24 0-50(00h-32h) Must be set to "24"
EX2 CC-POSITION 21 0-127(00h-7Fh)
EX3 INT 7A 0-255(00h-FFh) Must be set to "7A"
EX4 A-ATT 5A 0-127
OP1 OPTION1 BO 0-255(00h-FFh)
Must be set to "B7" (32R-S450,36R-S450), "A7" (CR32S45,CR36S45)
OP2 OPTION2 31 0-7(00h-07h) Must be set to "01"
ADJUSTMENT CONTENTS
Table - A
To Next Page
