Specifications, etc.
PC Supported signal timing
Resolution (pixel)
Horizontal
frequency
(kHz)
Vertical frequency
(Hz)
Input1
Input2〜4
Input6
Input7
A〜D
Input8
VESA
640 x 480 31.5 60 Yes Yes Yes Yes Yes
37.9 72 Yes Yes Yes No No
37.5 75 Yes Yes Yes No No
800 x 600 35.1 56 Yes Yes Yes No No
37.9 60 Yes Yes Yes Yes Yes
48.1 72 Yes Yes Yes No No
46.9 75 Yes Yes Yes No No
1024 x 768 48.4 60 Yes Yes Yes Yes Yes
56.5 70 Yes Yes Yes No No
60.0 75 Yes Yes Yes No No
1280 x 800 49.7 60 Yes Yes Yes Yes Yes
1366 x 768 47.7 60 Yes Yes Yes Yes Yes
1280 x 1024 64.0 60 Yes Yes Yes Yes Yes
1400 x 1050 65.3 60 Yes Yes Yes Yes Yes
• Depending on the PC connected, even the supported signals above may not be transmitted or displayed properly.
• For 8K input, see page 7-7.
8-1
2020/08/04 Sharp operation manual

Sharp 8M-B120C Specifications

General

Brand	Sharp
Model	8M-B120C
Category	Monitor
Language	English
