Connecting Other Devices
Connecting 8K output compatible Device/Quad-screen display（4K or less)
• Connects the Monitor to 8K output (7680 × 4320 of resolution output) compatible equipment by
using 4 HDMI cables.
• When connecting an 8K output compatible device to the Monitor, use commercially available
premium HDMI cables.
• Connect the devices properly so that the output signal from the device can be displayed at the
appropriate position.
Video images from the HDMI input terminal are displayed at the position as shown on the right
(default).
• Multi-screen display by using 8K signal is not supported.
• In MODE2, 8K display is possible whenever any input signal to INPUT 7 (A to D) is
synchronized.
• Under the factory default setting, INPUT7-A is set as the sound input.
• To change the factory default setting, switch to INPUT7, select "Setup" - " (Option)" -
"Terminal setting" - "INPUT7 audio setting" from the Menu, and then select input for audio
sound.
• Read the operation manual on the device to be connected to the Monitor as well.
◆Important◆
• Use / connect four HDMI cables of the same type and brand, otherwise performance cannot be
guaranteed.
• In Mode2, input the format 3840×2160 (24Hz, 25Hz, 30Hz, 50Hz, 60Hz) to each terminal of
INPUT 7 (A to D).
If any format other than the above is input, the video or picture may be distorted.
5-1
