Connecting Other Devices
Connecting 8K output compatible Device/Quad-screen display（4K or less)
How to change the display position in Mode3/4
• In mode 3, press the button for the input you want to display at the top left.
The display position of the selected screen and the upper left screen change.
• In mode 4, press the button for the input you want to display at the left side.
The display position of the selected screen and the left side screen change.
INPUT7-A:F1, INPUT7-B:F2, INPUT7-C:F3, INPUT7-D:F4
• To return initial display position, press CLEAR.
Supported audio sound signals
• Type: Linear PCM
• Sampling frequency: 48kHz / 44.1kHz / 32kHz
How to change the input audio sound in Mode2/3/4
• Press MENU, followed by / / / and ENTER to select "Setup" - " (Option)" - "Terminal setting" -
"INPUT7 audio setting", then select input for audo sound.
NOTE
• When "Audio input terminal" has been selected for "INPUT7 audio setting", no sound will come out of the
Monitor if you connect between the Monitor and a typical HDMI compatible device using an HDMI cable instead
of an analog audio cable. (An analog audio cable needs to be connected)
To connect the Monitor to a HDMI compatible device using an HDMI cable alone, select the input to which the
device has been connected in "INPUT7 audio setting".
5-4
