Sharp 8M-B32C1 - Page 29

29
E
Function Command Direction Parameter Reply Control/Response contents
COLOR
ADJUSTMENT
USER R-CONTRAST CRTR WR 0-256 0-256 “ERR” when WHBL is not set to 2.
G-CONTRAST CRTG WR 0-256 0-256
B-CONTRAST CRTB WR 0-256 0-256
R-OFFSET OFSR WR -127-127 -127-127
G-OFFSET OFSG WR -127-127 -127-127
B-OFFSET OFSB WR -127-127 -127-127
COPY TO USER CPTU W 0 Copies a preset value to the user setting.
COLOR GAMUT CLGM WR 0-7 0-7, 99 0: Rec.2020, 1: Rec.709, 2: SMPTE-C, 3: DCI-P3, 4: Adobe RGB, 5: sRGB, 6:
EBU, 7: THRU, 99: CUSTOM
GAMMA(EOTF) GAMM WR 0 0 1.8
1 1 2.2
2 2 2.4
5 5 2.0
10 10 1.6
11 11 2.6
12 12 A-LOG
13 13 A-LOG TO 1.6
14 14 A-LOG TO 1.8
15 15 A-LOG TO 2.0
16 16 A-LOG TO 2.2
17 17 A-LOG TO 2.4
18 18 A-LOG TO 2.6
21 21 21: THRU
22 22 22: HYBRID LOG GAMMA(HLG)
23 23 23: SMPTE ST 2084(PQ)
99 99: CUSTOM
HLG SYSTEM GAMMA HSGM WR 100-150 100-150 If set to 100 to 150, it is displayed as 1.00 to 1.50 on the monitor menu.
6-AXIS - HUE
CMHR WR -10-10 -10-10 R
CMHY Y
CMHG G
CMHC C
CMHB B
CMHM M
CRST W 1 Resets the hue.
6-AXIS - CHROMA
CMSR WR -10-10 -10-10 R
CMSY Y
CMSG G
CMSC C
CMSB B
CMSM M
CRST W 2 Resets the chroma.
6-AXIS - VALUE
CMVR WR -10-10 -10-10 R
CMVY Y
CMVG G
CMVC C
CMVB B
CMVM M
CRST W 3 Resets the color value.
CUSTOM SETTING
CMST WR 0 0 0: OFF
1 1 1: ON
ADVANCED UNIFORMITY LCUF WR
0 0
0: OFF
1 1
1: ON
DYNAMIC RANGE EXPAND
DMRE WR
1 1 1: MODE1
2 2 2: MODE2
3 3 3: MODE3
USER SETTING NAME (for
USER1)
CNM1 WR
XXXXXXXXXXXX XXXXXXXXXXXX INPUT MODE NAME (single-byte alphanumerical and symbols, up to 12
characters)
USER SETTING NAME (for
USER2)
CNM2 WR
XXXXXXXXXXXX XXXXXXXXXXXX INPUT MODE NAME (single-byte alphanumerical and symbols, up to 12
characters)
Controlling the Monitor with a computer
